Model Number
DFB20CCBL-1
41396-0-1119
INSTALLATION INSTRUCTIONS
FIREPLACE BARRIER FRAMES:
1.
Place the barrier screen on the front of the cast iron
fireplace. The brackets will engage the casting opening
between the glass and the cast iron frame. See Figure 1.
2.
Place one side of the barrier screen clips into the front
casting opening with the bottom clip placed to the bottom of
the cast iron frame opening.
3.
After engaging the clips with one side of the opening, pivot
the other side of the barrier screen inward until it snaps
into position.
Fits DV Cast Iron Stove Models
DVP20CC(30,70) Series
Figure 1
GAS-FIRED
Page 1
