INSTALLATION INSTRUCTIONS
DVCT50 LINER KIT
CERAMIC FIBER LINER
Model 50
DVP50PFB
LEAVE INSTRUCTIONS WITH THE HOMEOWNER.
CARTON CONTENTS
Description
LINER FRONT - LEFT
LINER FRONT - RIGHT
LINER SIDE - LEFT
LINER SIDE - RIGHT
LINER REAR - BOTTOM
LINER REAR - TOP
LINER TOP - CENTER
LINER TOP - LEFT
LINER TOP - RIGHT
BRACKET LINER
#10 X 1/2 SCREW
Tools needed: Phillips screw driver
Installation Of Front Liners
1.
Remove barrier screen and glass door.
(See the owner's manual for instructions)
2.
Place the RIGHT and LEFT FRONT LINER
as (Shown In Figure 1).
NOTICE: Video of liner installation available on our website at:
www.empirecomfort.com.
Empire Comfort Systems Inc. • Belleville, IL
Description
Fired Brick
Quantity Supplied
1
1
1
1
1
1
1
1
1
1
4
Figure 1
GAS-FIRED
Page 1
