Summary of Contents for Gima SUPERVEGA EVO BATTERY ASPIRATOR
- Page 1 Gima S.p.A. Via Marconi, 1 – 20060 Gessate (MI) Italy gima@gimaitaly.com – export@gimaitaly.com www.gimaitaly.com PROFESSIONAL MEDICAL PRODUCTS SUPERVEGA EVO BATTERY ASPIRATOR - 230 V Instruction manual 28183 Gima S.p.A. Via Marconi, 1 – 20060 Gessate (MI) Italy Made in Italy...
-
Page 2: General Warning
Do not place or store the aspirator in places where it may fall or be pulled into the bathtub or washbasin. In the event disconnect the mains switch, remove the plug from the power supply and contact the GIMA technical service it is accidentally dropped, do not attempt to remove the device from the water whilst the plug is still connected: and/or the GIMA technical service department. -
Page 3: Technical Characteristics
WARNING: Do not change this equipment without the permission of the manufacturer Gima S.p.A. None of electric or Instrument and accessory discharging must be done according to current regulations in the country of use. mechanical parts have been designed to be repaired by customers or end-users. Don’t open the device, do not mishandle the electric / mechanical parts. -
Page 4: Cleaning Device
CE marking in conformity with EC directive 93/42/CEE and subsequent changes General warnings and/or specifications Manufacturer: Gima S.p.A. Consult the instruction manual Via Marconi, 1 - 20060 Gessate (MI) Italy Applied Part type BF (suction probe) -
Page 5: Accessories Supplies
Don’t use after lapse of the sell-by date packaging. GIMA declines any liability for injury to the patient correlated to the deterioration of the above- Check the expiry date on the original packaging of the suction catheter and check the integrity of the sterile mentioned sterile packaging due to handling of the original packaging by third parties. - Page 6 Therefore, contact the manufacturer to request the assistance of an authorized and qualified technician when they need to The device is equipped with a Lithium-Ion Battery, which cannot be reached from the outside. Only refer to GIMA technical service be replaced.
- Page 7 2° case – If both the security system doesn’t work, there is the possibility that liquid comes inside the device, in this case return the GIMA S.p.A. will provide upon request electric diagrams, components list, descriptions, setting instructions and any other information that can help the technical assistance staff for product repair.
- Page 8 Filter assembling FLOW DIRECTION IN / Fluid Inside Suction Pump Jar Air Tube Inlet The device features an energy saving function which allows the device to increase its autonomy and decrease the number of revs of the motor. In order to do so, it controls the negative pressure which is generated only when the operator suctions body fluids. If the operator does not carry out the suction process the device lowers the number of revs of the motor, thus protecting the duration of the internal battery.
- Page 9 Recharging operations: to be able to charge the internal battery it is necessary to connect the universal switching adapter (mod. UE 60140429SPA1 of FUHUA) to the electric network for approx. 360 minutes with the main switch to position 0. The battery’s autonomy when fully charged is approx. 70 minutes with continued operations. LIGHT INDICATORS: The device is provided with a light indicator (directly on the LCD screen) which allows you to view the operation of the device, autonomy of the battery, and the charge phase in progress.
-
Page 10: Risk Of Electromagnetic Interference And Possible Remedies
The surgical SUPERVEGA EVO BATTERY ASPIRATOR is intended for use in the electromagnetic environment specifiedbelow. Guidance and manufacturer’s declaration – electromagnetic Emissions The customers or the user of the surgical SUPERVEGA EVO BATTERY ASPIRATOR should assure that it’s used in such an environment. The surgical SUPERVEGA EVO BATTERY ASPIRATOR only... - Page 11 The surgical SUPERVEGA EVO BATTERY ASPIRATOR is intended for use in the electromagnetic environment specified below. Guidance and manufacturer’s declaration – Immunity Emissions The customers or the user of the surgical SUPERVEGA EVO BATTERY ASPIRATOR should assure that it’s used in such an environme Immunity Test...
-
Page 12: Warranty Conditions
Instruments returned for repair MUST be accompanied by a description of the problem. GIMA will not be responsible for damage Failure to follow this procedure will result in the instrument being returned to the purchaser unrepaired. - Page 13 Gima S.p.A. Via Marconi, 1 – 20060 Gessate (MI) Italy gima@gimaitaly.com – export@gimaitaly.com www.gimaitaly.com PROFESSIONAL MEDICAL PRODUCTS Gima S.p.A. Via Marconi, 1 – 20060 Gessate (MI) Italy...
