Netbridge
Parameter Condition
Height
Width
Case only without rack ears
Depth
Weight (†)
Heat Dissipation 32 DSP, no I/O
Voltage Switch selectable
Current At 115V input
At 230V input
Fusing No external fuses
Noise
Connectors Power in
Network – TCP/IP
Network – SSL
Terminal
Serial
† Netbridge must be supported on rack shelves. Do not rely on the rack ears alone.
Value Unit
2 U
89 mm
19 in
432 mm
360 mm
11 kg
45 W
115 or 230 V
0.5 A
0.2 A
50 dB(A)
IEC male
RJ45
RJ45
9-way D-type male
62-way HD D-type female
Appendix A – Specifications
Notes
excludes connectors/cables
maximum
AC only
approximately
9-way breakout lead supplied
