C300HD Installation Guide
Digital I/O Card
AES/EBU IN
AES/EBU Input Connectors
9 - 16
1 - 8
25-pin D-type female
25 - 32
17 - 24
AES/EBU OUT
AES/EBU Output Connectors
9 - 16
1 - 8
25-pin D-type female
25 - 32
17 - 24
Page 32
MADI I/O Card
(Copper version)
MADI
LOCK
Rx
MADI Link A
A
BNC 75π
Tx
LOCK
Rx
MADI Link B
B
BNC 75π
Tx
IN
MADI Word Sync
WORD
BNC 75π
SYNC
OUT
IN
AES Sync
AES
SYNC
BNC 75π
OUT
