Figure 4 — SDI card mounted in place
5.
6.
7.

Part Numbers

Extron Part
SDI Output Card Kit
Extron Electronics, USA
1230 South Lewis Street
Anaheim, CA 92805
USA
714.491.1500
www.extron.com Fax 714.491.1517
www.camboard.de
CAMBOARD Electronics
Insert the card's installation screw through the SDI card's
mounting hole, and gently tighten it into the standoff.
Install the SDI connector's hex nut from the outside of the
rear panel opening. Keep the SDI card from twisting as the
nut is tightened.
Replace the top cover on the VSC, and fasten it with the
screws which were removed in step 3 of the "Cover
removal" section.
Rack/furniture mount the scan converter, and reconnect the
AC power cord.
