BCM91250E
F B
USES AND ATTERY
Figure 5 shows the positions of the fuses and battery alpha-numerically. Compare Figure 5's alpha-numeric
callouts with a description of each fuse or battery in Table 6.
.
Board ID
F1
F2
F3
BT1
Page 14

Fuses and Battery

Figure 5: Fuses and Battery Callouts

Table 6: Fuses and Battery Descriptions

Function
BCM1250 2.5V current limit, 5A.
BCM1250 3.3V current limit, 1A.
EJTAG 3.3V, 1A current limit fuse.
RTC battery.
B roadc om C or por ati on
User Manual
01/07/05
Document 91250E-UM100-R
