User Manual
01/07/05
Board ID
D1
D2
D7 *
D12 *
D13
D16
D18
* = LEDs visible from the board's side panel.
Document 91250E-UM100-R
Color
Description
Red
2.5V Fuse blown indicator
Red
3.3V Fuse blown indicator
Ethernet Port E1 PHY LEDs
Red
Link2 = Speed indicator.
Green
Link1 = Speed indicator.
Yellow
Fdx = Full-duplex indicator.
Green
Slv = Slave indicator.
Yellow
Act = Transmit and receive activity indicator.
Green
Link = Link quality indicator.
Ethernet Port E0 PHY LEDs
Red
Link2 = Speed indicator.
Green
Link1 = Speed indicator.
Yellow
Fdx = Full-duplex indicator.
Green
Slv = Slave indicator.
Yellow
Act = Transmit and receive activity indicator.
Green
Link = Link quality indicator.
Green
Debug LED.
Green
3.3V power good.
Green
5V.
B roadc om C or por ati on
Table 5: LED Descriptions
BCM91250E
LEDs
Page 13
