Pinout For Hypertransport Socket (J3); Table 2: Pinout For Hypertransport Socket (J3) - Broadcom BCM91250E User Manual

User Manual
01/07/05
P F
INOUT OR
Note: The table layout reflects the physical location of the pins on the connector. The middle pins
(121-132) are not shown though since they are all connected to ground (GND).
More information about these connectors can be found in "Web Resources" on page 19.
Odd Pin Name
VDD33
VDD33
VDDLDT
GND
TCK
TMS
TDI
TDO
TRST_L
SCL
SDA
LDT_RESET_L
LDT_PWROK
GND
LDT_RX_CTLn
LDT_RX_CTLp
GND
LDT_RX_CADn7
LDT_RX_CADp7
GND
GND
LDT_RX_CADn6
LDT_RX_CADp6
GND
LDT_RX_CADn5
LDT_RX_CADp5
GND
LDT_RX_CADn4
LDT_RX_CADp4
GND
Document 91250E-UM100-R
H S
YPERTRANSPORT

Table 2: Pinout For Hypertransport Socket (J3)

Odd Pin
Number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
B roadc om C or por ati on
(J3)
OCKET
Even Pin
Even Pin Name
Number
2 VDD33
4 VDD33
6 VDDLDT
8 GND
10 CLK100
12 GND
14 RDY
16 OE_L
18 WR_L
20 CS_L0
22 CS_L1
24 INT
26 RESET_L
28 GND
30 LDT_TX_CADp0
32 LDT_TX_CADn0
34 GND
36 LDT_TX_CADp1
38 LDT_TX_CADn1
40 GND
42 GND
44 LDT_TX_CADp2
46 LDT_TX_CADn2
48 GND
50 LDT_TX_CADp3
52 LDT_TX_CADn3
54 GND
56 LDT_TX_CLKp
58 LDT_TX_CLKn
60 GND
BCM91250E
Connectors Page 7
