5. Then you will be asked to pay the relevant amount. After
payment, a unique nontransferable file named "Activation.bin" will
be generated. It will then be sent to your e-mail.
6. Connect the DC-16 II to your computer and enable USB mode.
7. Copy the "Activation.bin" file to the transmitter SD card into the
root folder. The contents of the transmitter SD card can then look like
this:
8. Disconnect the transmitter from the computer (Do not forget to
confirm the safe hardware removal). Then confirm in your
transmitter that you want to update and restart it.
If the activation is successful, an informative table with a list of
modules appears immediately after switching on. Then it is
possible to operate the transmitter as usual.
computer radio control system

1.2 Features

Duplex 2.4GHz – the DC/DS transmitters feature the Duplex 2.4GHz,
frequency hopping, digital, data stream system, originally
developed by JETI model in the Czech Republic. This system has
been reliably used for many years.
Duplex 900MHz NG (Next Generation) - the DC-16 II transmitters
feature a backup wireless system for unmatched data transmission
safety and reliability.
Built-in Telemetry – from the start, the DC/DS transmitters were
designed and built with many attractive features and include the full
integration of all Duplex telemetry sensors.
Transmitters - the DC/DS designs use premium quality materials
and emphasize state-of-the-art appearance and user comfort.
Precise Gimbals – the transmitter gimbals are equipped with Hall
sensors and ball bearings for precision movement with an almost
unlimited lifespan.
LCD Display – color 3.5" TFT LCD display with 320 x 240 resolution
which is highly visable under any light conditions.
Li-Ion Battery – provides a proven and reliable energy source with a
high capacity (6200mAh) and a long service life.
Easy Charging – simply connect the wall power supply, optional car
charger, or any 12v Dc power supply to the transmitters charge port.
