Specifications - Mec 45-AJ Diesel Operator's Manual

Working Height*
Platform Height
Maximum Outreach
Maximum Up and Over Height
Turntable Swing
Jib Range Of Motion
Platform Rotation
Machine Weight** (Unloaded)
Lift Capacity
Unrestricted Standard
Maximum Occupants
Stowed Height
Overall Length
Overall Width
Tailswing
Wheel Base
Platform Details
Turning Radius, Inside
Ground Clearance
Lift Speed
Extend Speed
Jib Lift Speed
Drive Speed
(Proportional)
Raised or extended
Gradeability Stowed, downhill
Maximum Allowable
Operating Wind Speed
Engine
Fuel Type
Fuel Capacity
Hydraulic Fluid Capacity
Meets applicable requirements of ANSI A92.5-2006 and CSA
B354.4-2002.
Allowable ambient temperature range: -20° F to 120° F (-29° C to 49°C).
Consult with MEC for operation outside of this range.
*Working Height adds 6 feet (2 m) to platform height. **Weight may
increase with certain options.

—Specifications—

45-AJ Diesel
51 ft
45 ft
25 ft 2 in.
24 ft 6 in
Continuous
120°
180° (90° each side)
16,400 lbs
500 lb
98 in
23 ft 10 in
90.5 in
Zero
87 in
Width 72 in
Depth 40 in
Entry 1 End Swing Gate,
2 Slide Bar Entries
6 ft 6 in
12 in
35 sec
20 sec
15 sec
Stowed 0-3.6 mph
0-.5 mph
40%/22°
Stowed, uphill 40%/22°
28 mph
48 hp Kubota Diesel
Diesel
24 gal
49 gal
15.5 m
13.7 m
7.7 m
7.5 m
7,440 kg
227 kg
2
2.49 m
7.3 m
2.3 m
2.2 m
1.8 m
1 m
2 m
0.3 m
0-5.8 km/h
0-.8 km/h
12.5 m/sec
(45 km/h)
90 liter
185 liter
