INSTALLATION INSTRUCTIONS FOR OPTIMA
CONCEALED CLOSET AND URINAL FLUSHOMETERS
MODEL 150 ES-SM
MODEL 152 ES-SM
Unless otherwise noted, Sloan Valve Company warrants this product, manufactured and sold for commercial or industrial uses, to be free from defects in material and workmanship
for a period of three (3) years (one (1) year for special finishes, SF faucets, PWT electronics and 30 days for PWT software) from date of first purchase. During this period, Sloan Valve
Company will, at its option, repair, replace, or refund the purchase price of any product which fails to conform with this warranty under normal use and service. This shall be the sole
and exclusive remedy under this warranty. Products must be returned to Sloan Valve Company, at customer's cost. No claims will be allowed for labor, transportation or other costs.
This warranty extends only to persons or organizations who purchase Sloan Valve Company's products directly from Sloan Valve Company for purpose of resale. This warranty does not
cover the life of the batteries.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE COMPANY RESPONSIBLE FOR
ANY CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
SURFACE MOUNTED SENSOR ACTIVATED
MODEL 190 ES-SM
LIMITED WARRANTY
MODEL 194 ES-SM
Code No. 0816835
SYSTEMS
®
Concealed Closet
Flushometers
1" I.P.S. Outlet
• Model 150 ES-SM
1-1/2" Concealed Back Spud
• Model 152 ES-SM
Concealed Urinal
Flushometers
1-1/4" Concealed Back Spud
• Model 190 ES-SM
3/4" I.P.S. Outlet
• Model 194 ES-SM
3/4" Concealed Back Spud
• Model 195 ES-SM
MODEL 195 ES-SM
Rev. 1 (03/12)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 150 ES-SM and is the answer not in the manual?

Questions and answers

Related Manuals for Sloan 150 ES-SM

Summary of Contents for Sloan 150 ES-SM

  • Page 1 Unless otherwise noted, Sloan Valve Company warrants this product, manufactured and sold for commercial or industrial uses, to be free from defects in material and workmanship for a period of three (3) years (one (1) year for special finishes, SF faucets, PWT electronics and 30 days for PWT software) from date of first purchase. During this period, Sloan Valve Company will, at its option, repair, replace, or refund the purchase price of any product which fails to conform with this warranty under normal use and service.
  • Page 2 ROUGH-IN 150 ES-SM 152 ES-SM MODEL 150 ES-SM MODEL 152 ES-SM 152 ES-SM 150 ES-SM 152 ES-SM 152 ES-SM 150 ES-SM 152 ES-SM NOTE: Flush Connection shown with dotted lines is not included. 190 ES-SM 194 ES-SM 194 ES-SM 190 ES-SM...

  • Page 3: Tools Required For Installation

    • Phillips screwdriver • Drill – 1/16” and 1” drill bit • Wire stripper • Sloan A-50 Super-Wrench™, Sloan A-109 Plier Wrench or smooth jawed spud wrench !!! IMPORTANT !!! !!! IMPORTANT !!! Protect the chrome or special finish of Sloan Flushometers —...
  • Page 4 REPAIR KIT NOTE VACUUM BREAKER FLUSH CONNECTION Max. adjustment of Sloan Adjustable Tailpiece is ½” (13 mm) IN or OUT from the standard 4¾” (121 mm) (C/L of Valve to C/L of control stop). If roughing-in measurement exceeds 5¼” (133 mm),...

  • Page 5: Electrical Hook-Up

    (MODELS 150 & 152) 6 - ELECTRICAL HOOK-UP Be certain power is OFF to prevent damage to electrical components. Connect all cables EXACTLY as shown. WATER CLOSET URINAL MODEL 150 ES-SM MODEL 194 ES-SM SHOWN SHOWN EL-461 EL-497 WATER CLOSET...
  • Page 6 Open control stop COUNTERCLOCKWISE 1/2 turn from delivered properly cleanses the fixture. the closed position. !!! IMPORTANT !!! SLOAN FLUSHOMETERS ARE ENGINEERED FOR QUIET OPERATION. EXCESSIVE WATER FLOW CREATES NOISE, WHILE TOO LITTLE WATER FLOW MAY NOT SATISFY THE NEEDS OF THE FIXTURE.

  • Page 7: Operation

    When further assistance is required, please contact EL-101 or EL-166 nut from the solenoid operator. Remove the coil from the solenoid operator. Use a spanner wrench or Sloan Technical Support at: pliers to remove the EL-163-A solenoid shaft assembly from 1-888-SLOAN-14 valve.

  • Page 8: Care And Cleaning

    P ho ne : 1- 800-982- 58 3 9 o r 1- 8 47 -6 7 1- 43 0 0 • F a x: 1 -8 0 0- 4 4 7- 83 2 9 o r 1 - 8 47 - 6 7 1 - 4 3 8 0 • w w w. s lo a n v a lv e . c o m © 2012 SLOAN VALVE COMPANY...
