Installation of the Sloan OPTIMA™ equipped Flushometer provides the ultimate
in sanitary protection and automatic operation plus the water economy that
makes it the most advanced flushing system ever. There are no handles to trip
or buttons to push. The Flushometer uses adaptive infrared technology to sense
the user's presence and initiates the flushing cycle once the user steps away.
The OPTIMA equipped Flushometer is designed for easy installation and
maintenance and comes complete with the EL-1500-L OPTIMA sensor, cover
plate and attachment kit (with override button), 24 VAC solenoid operator,
Sloan Valve Company warrants its ES-S Sensor Operated Royal Flushometers to be made of first class materials, free from defects of material or workmanship
under normal use and to perform the service for which they are intended in a thoroughly reliable and efficient manner when properly installed and serviced, for
a period of three years (1 year for special finishes) from date of purchase. During this period, Sloan Valve Company will, at its option, repair or replace any part
or parts which prove to be thus defective if returned to Sloan Valve Company, at customer's cost, and this shall be the sole remedy available under this warranty.
No claims will be allowed for labor, transportation or other incidental costs. This warranty extends only to persons or organizations who purchase Sloan Valve
Company's products directly from Sloan Valve Company for purpose of resale.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE COMPANY
RESPONSIBLE FOR ANY CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
INSTALLATION INSTRUCTIONS
®
Bak-Chek
control stop with vandal resistant stop cap, adjustable tailpiece,
vacuum breaker flush connection and spud coupling, and wall and spud flanges
(for exposed piping). Specify transformer separately. One Sloan EL-154
transformer can operate up to ten OPTIMA Flushometers.
The following instructions will serve as a guide when installing the OPTIMA
equipped Flushometer. As always, good safety practices and care are
recommended when installing your new Flushometer. If further assistance is
required, contact your nearest Sloan Representative office.
LIMITED WARRANTY
OPTIMA™ SYSTEMS
SENSOR OPERATED
ROYAL FLUSHOMETER
CONCEALED & EXPOSED
CLOSET INSTALLATIONS
Exposed Closet Flushometer
1-1/2" Top Spud
Model 110/111 ES-S
Model 115 ES-S
Model 116 ES-S
Concealed Closet Flushometer
1-1/2" Exposed Back Spud
Model 140 ES-S
1-1/2" Exposed Top Spud
Model 153 ES-S
1-1/2" Concealed Back Spud
Model 152 ES-S
Made in the U.S.A.
Listed
Certified
EL-1500-L l.l.
Code No. 0816165
Rev. 2
Advertisement
Table of Contents
Related Manuals for Sloan 110 ES-S
Summary of Contents for Sloan 110 ES-S
-
Page 1: Installation Instructions
(1 year for special finishes) from date of purchase. During this period, Sloan Valve Company will, at its option, repair or replace any part or parts which prove to be thus defective if returned to Sloan Valve Company, at customer’s cost, and this shall be the sole remedy available under this warranty. - Page 2 FIXTURE BOX & FIXTURE BOX & FIXTURE MODEL 115 ES-S — Water Saver, 3.5 gpf (13.2 Lpf) MODEL 153 ES-S — Water Saver, 3.5 gpf (13.2 Lpf) MODEL 115-1.5 ES-S — Low Consumption, 1.6 gpf (6.0 Lpf) MODEL 153-1.5 ES-S — Low Consumption, 1.6 gpf (6.0 Lpf) MODEL 116 ES-S —...
-
Page 3: Prior To Installation
(mount in a convenient location) Flushometer and 15" (381 mm) for Model 115 ES-S or 17" (432 mm) for Model • 2-gang electrical box — 4" x 4" x 2-1/2" (102 mm x 102 mm x 64 mm) for 116 ES-S above the top of the closet fixture as shown in Figure 1. - Page 4 Step 3 — Install Vacuum Breaker Flush Connection (108 mm) MIN. 2-3/4" 5-1/4" MODELS 110/111 ES-S, 115 ES-S & 116 ES-S (Figure 6) (70 mm) ‡ (133 mm) MAX. Slide the Spud Coupling, Nylon Slip Gasket, Rubber Gasket and Spud Flange...
-
Page 5: Wiring Diagram
This will eliminate damage to chrome or special Note: A maximum of ten (10) sensor Flushometer units can operate from one (1) Sloan EL-154 transformer. Class 2 UL Listed, 48 VA (min.) at 24 VAC, plate mounted. - Page 6 (10) seconds and then moving it away. Adjust Control Stop after each flush until the rate of flow delivered properly cleanses the fixture. ® Important Note: The Sloan ROYAL Flushometer is engineered for quiet operation. Excessive water flow creates noise, while too little water flow may not satisfy the needs of the fixture.
-
Page 7: Care And Cleaning Instructions
within the effective range of the sensor. INSTRUCTIONS (Figure 16) 1. Thread the Plastic Sleeve onto the Stop Bonnet until it is snug (hand tight 3. When the user steps away from the OPTIMA Sensor, the loss of reflected only; do not use pliers or a wrench). light initiates an electrical “one-time”... - Page 8 For more information concerning OPTIMA and Royal Flushometer valve troubleshooting, consult Sloan OPTIMA and Royal Repair and Maintenance guides or contact your local Sloan Representative. If further assistance is required, please contact the Sloan Valve Company Installation Engineering Department at 847/671-4300.
-
Page 9: Parts List
The information contained in this document is subject to change without notice. For Models 110/111 ES-S: Code # 0816157 SLOAN VALVE COMPANY • 10500 Seymour Avenue • Franklin Park, IL 60131 • Ph: 847/671-4300 • Fax: 847/671-4380 http://www.sloanvalve.com Copyright © 1997 Sloan Valve Company...
