Appendix C Ports

Table 19 lists the fixed ports and slots on the device.
Table 19 Ports and slots
Item

Console port

USB port
Ethernet port
CF card slot
Interface module slot
Console port
Table 20 Console port specifications
Item
Connector
Standard compliant
Baud rate
Cable type
Transmission distance
Services

GE copper Ethernet port

The device provides twelve 10/100/1000BASE-T copper Ethernet ports.
Table 21 GE copper Ethernet port specifications
Item
Connector
Standard compliance
Interface type
Cable type
Transmission distance
Description
1, 9600 bps (default) to 115200 bps
1 (Host mode, Type A)
•
Twelve GE copper Ethernet ports
•
Twelve GE fiber Ethernet ports
•
Four 10GE fiber Ethernet ports
1
1, support for the NSQ1G24XS60 interface module
Specification
RJ-45
RS-232
9600 bps (default) to 115200 bps
Common asynchronous serial port cable
≤ 15 m (49.21 ft)
•
Connection to an ASCII terminal
•
Connection to the serial port of a local PC to run the terminal
emulation program
•
CLI
Specification
RJ-45
802.3, 802.3u, and 802.3ab
MDI/MDI-X autosensing
Category 5 or higher twisted pair cable
100 m (328.08 ft)
