Figure 29 PSR300-12A2 AC power module
(1) Power switch
(3) Power receptacle
Table 16 PSR300-12A2 AC power module specifications
Item
Rated input voltage range
Maximum input current
Maximum power

DC power module

The PSR300-12D2 DC power module is available for the device. It provides a maximum output of
300 W.
Figure 30 PSR300-12D2 DC power module
(1) Power switch
(3) Power receptacle
Table 17 PSR300-12D2 DC power module specifications
Item
Rated input voltage range
Maximum input current
Maximum power
(2) Handle
Specification
100 VAC to 240 VAC @ 50 Hz or 60 Hz
4 A
300 W
(2) Handle
Specification
–48 VDC to –60 VDC
10 A
300 W
