h I d d e n h o r n s
f I ts : ' 93 - uP tou r I ng mo d els ( dr ess ers , road k Ing , road g lI de , an d s tr e e t
g lI d e ) . n o t c omPatI bl e w Ith h- d to ur Ing d etachab le d oc kI n g kI ts ( 53 80 3- 0 6
a n d 53 8 0 4 - 0 6) .
Part#
907738
Please read and understand entire instructions before starting installation.
thank you for choosIng küryakyn!
Please note
It is the installers' responsibility to make sure all fasteners (including pre-assembled) are
tightened before operation of motorcycle. Küryakyn will not warranty components that are
lost due to improper installation. Periodic maintenance may be required.
tools suggested
Torx wrench set, set of hex wrenches, set of combination wrenches, Phillips screwdriver, and
general-purpose thread locker.
ATTenTIon! A factory service manual may be helpful in performing this installation. Do not
attempt to perform this installation if you are not confident in your ability to complete all
steps in the procedure; consult a trained technician.
ATTenTIon! When routing the wiring harness, be sure to keep the wiring away from any
moving parts, pinch points or extreme heat. Küryakyn WILL NOT warranty any electrical
component that fails due to pinched, crimped, broken, abraded, melted or frayed wires.
CauTION! avOId pOTeNTIaL eLeCTrICaL shOCk! Be sure TO COmpLeTeLy
dIsCONNeCT The BaTTery BefOre sTarTINg ThIs prOCedure.
note
Installation shown on a 2004 FLHR; while representative of typical procedure,
there may be minor differences when installed on other models.
Procedure
steP 1 Park the motorcycle on a hard, level surface.
steP 2 Shut off ignition and allow engine to cool.
-cont.-
7738-11hd-1206
Included
1
Hidden Horns Assembly
1
Wiring Harness
1
"Y" Harness
1
Hardware Kit, including:
3
5/16-18 x 3/4" HHCS
3
5/16" Flat Washer
1
3/4" x 5/16" x 1/2" Spacer
1
3/4" x 5/16" x 3/4" Spacer
4
18" long black vinyl sheathing
10 Cable ties
2
Dielectric grease
1
Installation Instructions
7 7 3 8
