PELLET GRILL
Model number: CG2310601-MM-00
ASSEMBLY & OPERATING INSTRUCTIONS
 Please read this entire manual before installation and use of this pellet
fuel-burning appliance.
 Follow all warnings and instructions when using the appliance.
 Failure to follow these instructions could result in property damage, bodily
injury or even death.
 Contact local building or fire officials about restrictions and installation
inspection requirements in your area.
 Save these instructions.
For assistance, contact customer service at
1-888-837-1380
or at
For Outdoor Use Only
Should you encounter any problem,
CALL US FIRST.
Do not return product to the store.
WE CAN HELP.
, Mon to Fri, 8:00am – 5:00pm Pacific Standard time
1 of 32
customerservice@rankam.com
20191202-Ver.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG2310601-MM-00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Member's Mark CG2310601-MM-00

Summary of Contents for Member's Mark CG2310601-MM-00

  • Page 1 PELLET GRILL Model number: CG2310601-MM-00 ASSEMBLY & OPERATING INSTRUCTIONS For Outdoor Use Only  Please read this entire manual before installation and use of this pellet fuel-burning appliance.  Follow all warnings and instructions when using the appliance.  Failure to follow these instructions could result in property damage, bodily injury or even death.

  • Page 2: Safety Labels

    WARNINGS SAFETY LABELS DANGER: Indicates an imminent hazardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
  • Page 3 WARNING Important Safety Instructions When using electrical appliances, basic safety precautions should always be followed, including the following:  READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE APPLIANCE.  This grill is for outdoor use only. Do not use it in any enclosed area. ...
  • Page 4  Maintain a minimum clearance of 60 inches (152.4 cm) between all sides of grill, deck railings, walls or other combustible material. DO NOT use grill under any overhead combustible construction.  To protect against electric shock, wear protective gloves such as oven mitts at all times when using appliance.
  • Page 5 WARNING When using electrical appliances, basic safety precautions should always be followed, including the following:  Electrical Rating: 120 Volts / 60 Hz / 250W, Phase 1.  Must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, Part I, CSA C22.1 when install this appliance.
  • Page 6 WARNING  Creosote - Formation and need for removal. When wood pellets are burned slowly, they produce tar and other organic vapors that combine with expelled moisture to form creosote. The creosote vapors condense in a relatively cool oven flue and exhaust hood of a slow burning fire.

  • Page 7: Product Diagram

    PRODUCT DIAGRAM 7 of 32 20191202-Ver.1.0...

  • Page 8: Component List

    COMPONENT LIST 1. Warming Rack 2. Cooking Grate 3. Lid Handle Heat Shield Qty: 1pc Qty: 3pcs Qty: 1pc 4. Lid Handle 5. Side Handle Tray 6. Flame Tamer Qty: 1pc Qty: 1pc Qty: 1pc 7. Meat Probe 8. Grease Drip Tray 9.
  • Page 9 13. Grease Bucket 14. Grease Drain Assembly 15. Front Shelf Left Bracket Qty: 1pc Qty: 1pc Qty: 1pc 16. Front Shelf Right Bracket 17. Front Shelf 18. Cart Bottom Panel Qty: 1pc Qty: 1pc Qty: 1pc 19. Left Rear Leg 20.

  • Page 10: Hardware List

    HARDWARE LIST Item No. Item name Diagram M6x12mm Bolt M6 Nut M6x20mm Bolt Wheel Sleeve M10 Locking Nut M10 Washer Heat Insulating Washer M6x14mm Bolt M6x15 Nut 10 of 32 20191202-Ver.1.0...
  • Page 11 Symbol: The following symbols will be shown in each procedure to show how the nut and bolt should be tightened. Hand Tighten Tighten with tools WARNING  Please wear gloves while assembling the grill. 11 of 32 20191202-Ver.1.0...
  • Page 12 Replacement Part List (I) 12 of 32 20191202-Ver.1.0...
  • Page 13 Replacement Part List (II) Part Part Name Part Part Name Number Number Warming Rack Cooking Grate Lid Handle Heat Shield Lid Handle Side Handle Tray Flame Tamer Meat Probe Grease Drip Tray Grill Body – Hopper Lid Grill Body Assembly Grill Body –...

  • Page 14: Assembly Procedures

    ASSEMBLY PROCEDURES Step 1. Attach the Legs (19, 20, 23 & 24) to the Grill Body Assembly (9) using 16 pcs bolt (A) as shown below. Please make sure that all the legs are in right position and direction. Step 2. Attach the Cart Bottom Panel (18) to the legs using 4 pcs bolt (A). 14 of 32 20191202-Ver.1.0...
  • Page 15 Step 3. Lock the Locking Casters (25) then insert them into the threaded holes on the bottom of the right legs as shown. Tighten the caster by turning in clockwise until it is fully secured. Step 4. Attach the Wheels (26) and Wheel Axles (21) to the left legs using 2 sets wheel sleeves (D), washers (F) and bolts (E) as shown.
  • Page 16 Step 5. Attach the Cart Front Panel (22) to the cart using 4 pcs bolt (A). Step 6. Tighten all the bolts and nuts on the cart. 16 of 32 20191202-Ver.1.0...
  • Page 17 Step 7. Attach the Lid Handle (4) and Lid Handle Heat Shield (3) to the lid using 2 sets heat insulating washer (G), nut (B) and bolt (H) as shown. Step 8. Attach the Grease Drain Assembly (14) to the grill body using 4 pcs bolt (A) as shown.
  • Page 18 Step 9. Attach the Smoke Stack Assembly (10) to the grill body using 3 pcs bolt (A) and nut (B) as shown. Step 10. Attach the Side Handle (11) to the grill body using 4 pcs bolt (A) as shown. 18 of 32 20191202-Ver.1.0...
  • Page 19 Step 11. Attach the Front Shelf Brackets (15 & 16) to the grill body using 4 sets bolt (A) and nut (B) as shown. Please make sure that all the brackets are in right position and direction. Step 12. Attach the Front Shelf (17) to the front shelf brackets using 2 sets bolt (C) and nut (I) as shown.
  • Page 20 Step 13. Place the Flame Tamer (6) on the holding bracket as shown. Step 14. Place the Grease Drip Tray (8) in the grill body as shown. 20 of 32 20191202-Ver.1.0...
  • Page 21 Step 15. Place the Cooking grate (2) on the grill body as shown. Step 16. Place the Warming Rack (1) on the grill body as shown. 21 of 32 20191202-Ver.1.0...
  • Page 22 Step 17. Place the Side Handle Tray (5), Hook (12) and Grease Bucket (13) on the side handle and grill body as shown. Step 18. Your unit is fully assembled! Make sure to read and follow the Instruction Manual before using this appliance. 22 of 32 20191202-Ver.1.0...

  • Page 23: Initial Lighting Instructions

    OPERATING INSTRUCTIONS WARNING  Only Dia 6 mm Pellets can be used. INITIAL LIGHTING INSTRUCTIONS 1. Read instructions before lighting. 2. Open the lid and take out the cooking grate, grease drip tray and flame tamer. 3. Make sure the control knob is in the “OFF” position. 4.

  • Page 24: Subsequent Start-Up

    SUBSEQUENT START-UP Set the control knob to “SMOKE” with the lid open. LCD will show the grill temperature. When the grill temperature reaches 180°F, LCD will show “SoC”. At “SMOKE” position, auger will keep continuously feeding the pellet for 6 minutes or if grill temperature is above 180° F, auger will stop feeding.

  • Page 25: Shutting Off Your Grill

    d. Confirm the draft inducer fan is working by holding your fingers above the firepot to feel the blowing air through the firepot. 5. If one or all of the above are not working, see the trouble shooting section or contact customer service.
  • Page 26 flame could come out from the firepot and cause a grease fire in your grill. 6. Never move your grill while running. 7. Never put water into the pellet hopper or firepot. 8. Never add pellets to firepot directly. It is dangerous. If you run out of pellets and lose your fire while cooking, let the grill cool down and start again with the INITIAL LIGHTING INSTRUCTIONS.

  • Page 27: Using Wood Pellet Fuel

    USING WOOD PELLET FUEL Wood pellets appear no thicker than the eraser on the end of a pencil. People who see them for the first time think they look like rabbit food; however, there is nothing small about the heat or flavor in barbecue wood pellet fuel.

  • Page 28: Maintenance And Cleaning Instructions

    MAINTENANCE & CLEANING INSTRUCTIONS CAUTION  Make sure your grill is OFF and cold completely before performing any maintenance and cleaning. STEEL SURFACES There are different stainless steel cleaners available. Always use the mildest one for cleaning first and scrubbing in the direction of the grain. To touch up noticeable scratches in the stainless steel, sand very lightly with dry 100 grit emery paper in the direction of the grain.

  • Page 29: Hopper Assembly

    HOPPER ASSEMBLY The hopper includes a clean-out feature to allow for ease of cleaning and change out of pellet fuel flavors. Before empty the hopper, place a clean and empty pail under the pellet extractor tube (part number 9d) then pull the pellet extractor handle (part number 9j) outwards to release the pellets from hopper.

  • Page 30: Digtal Thermostat Control Wiring Diagram

    DIGTAL THERMOSTAT CONTROL WIRING DIAGRAM 30 of 32 20191202-Ver.1.0...

  • Page 31: Troubleshooting

    TROUBLE SHOOTING Problem: Possible Causes: Corrective Actions: 1. Make sure the power cord is plugged in. Verify there is power at the electrical outlet. 2. Remove the control, check the fuse on back. Replace the fuse if blown out. 3. If both of the Draft Inducer Fan and 1.

  • Page 32: Limited Warranty

    LIMITED WARRANTY Manufacturer warrants this Product to be free from defects in workmanship and materials for a period of Ninety (90) days from the date of purchase, PROVIDED claims are submitted, in writing, with proof of purchase. If any part of this item fails because of a manufacturing defect within the Limited Warranty Period, Manufacturer offers to replace such part(s) provided that such parts have not been improperly repaired, altered, or tampered with or subject to misuse, abuse or exposed to corrosive conditions.
