www.adeept.com
Connect the IR Receiver to D14 with
the Female to Female Dupont Wire
Connect to the corresponding
interfaces on AdeeptPixie according
to different colors.
Connect to the interfaces from
D2 to D13 in turn according to
the servo number given above.
GND
D
5V
50
