Tools; Self-Prepared Parts - ADEEPT Quadruped Robot Manual

1.4.Tools

Cross Screwdriver X1
Large Cross-head Screwdriver X1
Flathead Screwdriver X1
Winding Pipe X1
Ribbon X1

1.5.Self-prepared Parts

18650 Battery X2
18650 battery specification:
It is recommended to use lithium battery above 3000mAh and without overcurrent
protection. The power supply current requirement is above 3A. Using 18650 lithium
battery with overcurrent protection function, 18650 battery whose capacity is less than
1700mAh, 18650 battery specially for strong-light flashlight, 18650 battery with power
shortage or counterfeit lithium battery produced by informal manufacturers will cause the
unstable work of the robot,power cut and even damage to the Raspberry Pi and robot.
The robot can be turned on normally,but the robot will automatically restart or shut down
after, also because of the problem caused by the 18650 battery.
300mm*2
Cross Socket wrench
7
www.adeept.com
X1
