HDMI 2.0 4K UHD SPLITTER 4 PORT WITH EDID

INSTALLATION

HDMI splitter
1. Connection:
Connect the HDMI video source output port to the splitter input port by HDMI cable
Connect the splitter output port to HDMI display by HDMI cable
Set the TV input to right HDMI channel
Power on the splitter (Power indicator led will light on)
2. Operation:
Before output HDMI signal, the splitter will read EDID information of connected TVs and
send back to HDMI source part to let it determine the output mode
Indicator led shows the working status
The splitter is build-in 16 kinds of EDID that can be selected by 4 switch codes, corresponding
as following:
DVD
TV
TV
o
N 1 2 3 4
1 2
0 0
1 0
0 1
1 1
0 0
1 0
0 1
1 1
0 0
1 0
0 1
1 1
0 0
1 0
0 1
1 1
TV
TV
o
N 1 2 3 4
3 4
0 0 4k@ 60H z 2 CH
0 0 4k@ 60H z 7 .1CH
0 0 4k@ 30H z 2 CH
0 0 4k@ 30H z 7 .1CH
1 0 1080p @ 60H z 2 CH
1 0 1080p @ 60H z 7 .1CH
1 0 1080i @ 60H z 2 CH
1 0 1080i @ 60H z 7 .1CH
0 1 720p @ 60H z 2 CH
0 1 720P@ 60H z 7 .1CH
0 1 480P@ 60H z 2 CH
0 1 480p @ 60H z 7 .1CH
1 1 Co p y o n ce
1 1 M IX1
1 1 M IX2
1 1 M IX3
