Sunjoy L-GZ472PST-ICL Assembly Instructions

Assembly Instructions

Item#: L-GZ472PST-ICL

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble

or install the product.

WARNING

Keep all children and pets away from assembly area. Children and pets should

be supervised when they are in the area.

Keep all flame and heat sources away from the tent fabric. This tent is made with

fabric that meets CPAI-84 specification for flame resistance. It is not fireproof. The

fabric will burn if left in continuous contact with any flame sources. The application

of any foreign substance to the tent fabric may render the flame-resistant properties

ineffective.

Before beginning assembly of product, make sure all parts are present. Compare

parts with package contents list.If any part is missing or damaged, do not attempt

to assemble the product.

Table of Contents

Do you have a question about the L-GZ472PST-ICL and is the answer not in the manual?

Page 1 Assembly Instructions Item#: L-GZ472PST-ICL SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble or install the product. WARNING Keep all children and pets away from assembly area. Children and pets should be supervised when they are in the area.
Page 2 No Tools Required for Assembly. Important: For technical assistance on assembly or replacement parts. Please call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 4:30 PM EST Monday to Friday or fax the replacement part form which is in the box to (740)-283-3549 or Email customer.care@sunjoydirect.com for assistance.
Page 3 Fig.2: Use the plastic rings to hang the new mosquito netting (A) onto the crossbeams. Note: Be mindful of the dimensions of the item to ensure you install the mosquito netting (A) correctly; the sides with 7 plastic rings (from the zippers to the corners) should hang on the long crossbeams and the sides with just 6 plastic rings should hang on the short crossbeams.
