■ BCD DATA (32-bit data, models: R3-BA32A, BC32A, etc.)
32-bit binary data is used for BCD.
Lower 16 bits are allocated from the lowest address to higher ones, higher 16 bits in turn.
15
+0
15
+1
■ DISCRETE DATA (models: R3-DA16 and DC16, etc.)
15
0 : OFF
1 : ON
0
Lower 16 bits
0
Higher 16 bits
0
Input 1 (Output 1)
Input 2 (Output 2)
Input 3 (Output 3)
:
Input 16 (Output 16)
