Danfoss TMT W FL Repair Instruction page 10

Repair Instruction
Spare Part List TMT
Mounting Flange Module Number (continued)
Nr. Note Item
1) 2
1) 3
Shaft Module Number
Nr. Note Item
M3 8
5
7
6
Nr. Note Item
M4 9
Nr. Note Item
M5 11
10
Motor Flange Module Number
Nr. Note Item
M6 13
12
1) 3
Nr. Note Item
M6 13
12
1) 3
10
Orbital Motors TMT, TMT FL and TMT W FL
Spare Parts (Metric Version)
Shaft seal 1.97×2.83×9,31 in
O-ring 4.91×008 in
Spare Parts (SAE Version)
Tapered shaft 1 3/4"
1 : 8 incl. bearings
Nut 1 1/4 UN
Parallel key 1/16 × 7/16 × 1 1/4
Washer is not included in the module
Spare Parts (SAE Version)
Splined shaft 1.5" incl. bearings
Spare Parts (SAE Version)
Cylindrical shaft ∅1.5"
incl. bearings
Parallel key 3/8 × 3/8× 2 1/4
Spare Parts (SAE Version)
Motor flange TMT 250 - TMT 470 with drainport SAE 9/16-18 UNF
Drain plug (plastic) SAE 9/16 - 18 UNF
O-ring 4.91×0.08 in
Spare Parts (SAE Version)
Motor flange TMT 500 - TMT 630 with drainport SAE 9/16-18 UNF
Drain plug (plastic) SAE 9/16 - 18 UNF
O-ring 4.91×0.08 in
520L0351 • Rev EA • Feb 2014
Code No.
Code No.
151Z2028
Code No.
151Z2006
Code No.
151Z2029
Code No.
151Z2000
Code No.
151Z2194
