Spare Part List Tmt - Danfoss TMT W FL Repair Instruction

Repair Instruction

Spare Part List TMT

Mounting Flange Module Number
Nr. Note Item
M1 1
1) 2
1) 3
Nr. Note Item
M2 4
1) 2
1) 3
Shaft Module Number
Nr. Note Item
M3 8
5
7
6
Nr. Note Item
M4 9
Nr. Note Item
M5 11
10
Motor Flange Module Number
Nr. Note Item
M6 13
12
1) 3
Nr. Note Item
M6 13
12
1) 3
1) Contained in set of seals, see Spare Part List TMT FL
Mounting Flange Module Number
Nr. Note Item
M2 4
Orbital Motors TMT, TMT FL and TMT W FL
Spare Parts (Metric Version)
Mounting flange with pilot ∅160 mm and BC ∅200 mm
Shaft seal 50×72×8 mm
O-ring 125×2 mm
Spare Parts (Metric Version)
Mounting flange with pilot ∅125 mm and BC ∅160 mm
Shaft seal 50×72×8 mm
O-ring 125×2 mm
Spare Parts (Metric Version)
Tapered shaft ∅45 mm
1 : 10 incl. bearings
Nut M 30×2 mm
Parallel key 28×12×8 mm
Washer 56×31×4 mm
Spare Parts (Metric Version)
Splined shaft 1.5" incl. bearings
Spare Parts (Metric Version)
Cylindrical shaft ∅40 mm incl. bearings
Parallel key 70×12× 8 mm
Spare Parts (Metric Version)
Motor flange TMT 250 - TMT 470 with drain port G ¼"
Drain plug (plastic) G = ¼"
O-ring 125×2 mm
Spare Parts (Metric Version)
Motor flange TMT 500 - TMT 630 with drain port G 1/4"
Drain plug (plastic) G = ¼"
O-ring 125×2 mm
on page 29
Spare Parts (Metric Version)
Mounting flange module with pilot ∅5 in and BC ∅6.374 in
520L0351 • Rev EA • Feb 2014
Code No.
151Z2001
Code No.
151Z2002
Code No.
151Z2005
Code No.
151Z2037
Code No.
151Z2017
Code No.
151Z2058
Code No.
151Z2195
Code No.
151Z2015
9
