Danfoss TMT W FL Repair Instruction page 16

Repair Instruction
Spare Part List TMT
End Cover Module Number prepared for Flushing Valve (continued)
Nr. Note Item
27
28
29
40
1) 2) Contained in set of seals - see
End Cover Module with Main Port Connection
Nr. Note Item
M9 30
21
22
2) 23
24
25
26
2) 27
28
29
40
29.1
End Cover Module Number
Nr. Note Item
M10 30
21
1) 2) 22
1) 2) 23
1) 2) 24
1) 2) 25
26
27
28
29
40
16
Orbital Motors TMT, TMT FL and TMT W FL
Spare Parts (Metric Version)
Guide pin 14×5 mm
Spacer
Main port plug (plastic)
3/4" 2 pcs.
Name plate
Spare Part List TMT FL on page 29
Spare Parts (SAE Version)
1 1/16" - 12 UN and drain port
9/16" - 18 UF
Balance plate
Back-up ring, 66.6×1 mm 2 pcs.
O-ring 63×2 mm
Back-up ring 44.1×1 mm
O-ring 40×2 mm
Spring 18×3.6 mm 6 pcs.
Guide pin 14×5 mm
Spacer
Main port plug (plastic)
1 1/16" - 12 UN 2 pcs.
Name plate
Drain plug (plastic) 9/16" - 18 UNF
Spare Parts (SAE Version)
End cover with
port connection 1 1/16-12 UN
Balance plate
Back-up ring, 2.62×0.04 in 2 pcs.
O-ring 2.48×0.08 in
Back-up ring 1.74×0.04 in
O-ring 1.57×0.08 in
Spring 0.70×0.14 in 6 pcs.
Guide pin 0.55×0.20 in
Spacer
Main port plug (plastic)
1 1/16-12 UN 2 pcs.
Name plate
520L0351 • Rev EA • Feb 2014
Code No.
Code No.
151Z2042
Code No.
151Z2040
