Parts Needed
Nuts & Bolts used
in this step are
highlighted in YELLOW
2x
416 mm Channel
Cutaway section on 288 mm
Channel is only illustrated to
show detail. This part is not
12x
1/2" Socket
Head Cap Screw
meant to be cut.
Middle Frame Step 8
12x
Kep Nut
55
55
