Table of Contents EV3 Addendum to Mr. Robot ..... I-XII Part 1 – Base Frame ........ 2-25 Part 2 – Base Complete ......26-43 Part 3 – Middle Frame ......44-59 Part 4 – Hand ........60-70 Part 5 – Left Arm ........71-86 Part 6 –...
Addendum to Mr. Robot build instructions on how to attach the new LEGO EV3 programmable brick to Mr. Robot. • The LEGO® NXT Brick has been replaced by the EV3 Brick. Mr. Robot now ships with EV3 and a newer-style wireless controller and sensor module.
Page 6
PSP-Nx. If the receiver is connected properly to PSP- Nx, and NXT/EV3 is powered ON (without running any program), PSP-Nx will have no lights. Adjacent picture shows location of the light on PSP- Nx-v4. EV3 Addendum to Mr. Robot...
Page 7
Power off and on your Joystick and press this button to reset connection between the Joystick and receiver. Set the Joystick in Analog mode. Press the Analog button on your Joystick once to set it in Analog mode. EV3 Addendum to Mr. Robot...
Page 8
Intelligent Brick LEGO® Beam 13M TETRIX® Hard Point Connectors 39120 Socket Head Cap Screws LEGO® 2x4 Angle Beam LEGO® 3x5 Angle Beam 6-32 x 5/16" 39098 Kep Nuts 39094 Partial assembly should look like this. EV3 Addendum to Mr. Robot...
Page 9
Step 1.0 Step 1.1 EV3 Addendum to Mr. Robot...
Page 10
Step 1.2 Step 1.3 Note: These are each a LEGO® Beam 15M. EV3 Addendum to Mr. Robot...
Page 11
Step 1.4 Step 1.5 EV3 Addendum to Mr. Robot...
Page 12
Step 1.6 Step 1.7 VIII EV3 Addendum to Mr. Robot...
Page 13
Step 1.8 Step 1.9 EV3 Addendum to Mr. Robot...
Page 14
Step 1.10 Step 1.11 EV3 Addendum to Mr. Robot...
Page 15
Finished Assembly EV3 Addendum to Mr. Robot...
Page 16
View 2 Parts Needed LEGO® Connection Peg w Axle Mindsensors PSP Sensor with Jack PS2 Dongle Finished assembly should look like this. EV3 Addendum to Mr. Robot...
Page 17
Step 2.0 Step 2.1 XIII EV3 Addendum to Mr. Robot...
Page 18
Step 2.2 Finished Assembly EV3 Addendum to Mr. Robot...
Page 20
Left Foot Step 1 Parts Needed 144 mm Angle 416 mm Channel 1/2" Socket Kep Nut Head Cap Screw...
Page 21
Left Foot Step 2 Parts Needed 288 mm Channel 64 x 192 mm Kep Nut Building Plate 160 mm Channel 1/2" Socket Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 22
Left Foot Step 3 Parts Needed 160 mm Channel 1/2" Socket Kep Nut Head Cap Screw...
Page 23
Left Foot Step 4 Parts Needed 32 mm Channel 1/2" Socket Kep Nut Head Cap Screw...
Page 24
Left Foot Step 5 Parts Needed 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 25
Left Foot Step 6 Parts Needed 32 mm Channel 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 27
Right Foot Step 1 Parts Needed 144 mm Angle 288 mm Angle Kep Nut 416 mm Channel 1/2" Socket Head Cap Screw...
Page 28
Right Foot Step 2 Parts Needed 288 mm Channel 64 x 192 mm Kep Nut Building Plate 160 mm Channel 1/2" Socket Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 29
Right Foot Step 3 Parts Needed 160 mm Channel Kep Nut 1/2" Socket Head Cap Screw...
Page 30
Right Foot Step 4 Parts Needed 32 mm Channel 1/2" Socket Kep Nut Head Cap Screw...
Page 31
Right Foot Step 5 Parts Needed 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 32
Right Foot Step 6 Parts Needed 32 mm Channel 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 34
Left Leg Step 1 Parts Needed Kep Nut 416 mm Channel 160 mm Channel 288 mm Channel 1/2" Socket Head Cap Screw Cutaway section on 288 mm Channel is only illustrated to show detail. This part is not meant to be cut. Nuts &...
Page 35
Left Leg Step 2 Parts Needed 416 mm Channel 288 mm Channel 1/2" Socket Kep Nut Head Cap Screw Cutaway section on 288 mm Channel is only illustrated to show detail. This part is not meant to be cut. Nuts & Bolts used in this step are highlighted in YELLOW...
Page 36
Left Leg Step 3 Parts Needed 96 mm Channel 1/2" Socket Kep Nut Head Cap Screw...
Page 37
Left Leg Step 4 Parts Needed 10 x 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 38
Left Leg Step 4 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 39
Right Leg Step 1 Parts Needed Kep Nut 416 mm Channel 160 mm Channel 1/2" Socket 288 mm Channel Head Cap Screw Cutaway section on 288 mm Channel is only illustrated to show detail. This part is not meant to be cut. Nuts &...
Page 40
Right Leg Step 2 Parts Needed 416 mm Channel 288 mm Channel 1/2" Socket Kep Nut Head Cap Screw Cutaway section on 288 mm Channel is only illustrated to show detail. This part is not meant to be cut. Nuts & Bolts used in this step are highlighted in YELLOW...
Page 41
Right Leg Step 3 Parts Needed 96 mm Channel Kep Nut 1/2" Socket Head Cap Screw...
Page 42
Right Leg Step 4 Parts Needed 10 x 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 43
Right Leg Step 4 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 44
Base Step 1 Parts Needed Kep Nut 1/2" Socket Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 45
Base Step 2 Parts Needed Tank Tread 18" Motor Motor Shaft Sprocket Power Cable 1/2" Socket 152 RPM DC Motor Mount Head Cap Drive Motor Screw Attach DC Motor Power Lead to back of motor...
Page 46
Base Step 2 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 47
Base Step 2 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 48
Base Step 3 Parts Needed Tank Tread Bronze Axle Set Sprocket Bushing Collar 100 mm Axle Axle Hub 1/8" Axle Spacer Repeat for each of the 16 wheels. x 16...
Page 49
Base Step 4 Parts Needed Bronze Bushing...
Page 54
Leg Step 1 Parts Needed 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 55
Leg Step 2 Nuts & Bolts used in this step are highlighted in YELLOW...
Page 56
Leg Step 3 Nuts & Bolts used in this step are highlighted in YELLOW...
Page 57
Leg Step 4 Nuts & Bolts used in this step are highlighted in YELLOW...
Page 58
Leg Step 5 Parts Needed HiTechnic DC 5/16" Socket Head Kep Nut Motor Controller Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 59
Leg Step 6 Nuts & Bolts used in this step are highlighted in YELLOW...
Page 60
Leg Step 7 Parts Needed On/Off Switch 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 62
Middle Frame Step 1 Parts Needed 416 mm Channel 160 mm Channel 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 65
Middle Frame Step 4 Parts Needed Kep Nut 64 x 192 mm TETRIX Building Plate Hard Point Technic 15M Connector Peg 5/16" Socket *Cut down to Connector Beam w/ Friction 3M Head 160 mm Cap Screw...
Page 69
Middle Frame Step 6 Parts Needed 64 x 192 mm Building Plate 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 70
Middle Frame Step 6 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 72
Middle Frame Step 7 Parts Needed Kep Nut 1/2" Socket 416 mm Channel Gear Hub Head Cap Spacer Pack Screw 160 mm Channel Single Servo Motor Bracket...
Page 73
Middle Frame Step 8 Parts Needed 416 mm Channel 1/2" Socket Kep Nut Head Cap Screw Cutaway section on 288 mm Channel is only illustrated to show detail. This part is not meant to be cut. Nuts & Bolts used in this step are highlighted in YELLOW...
Page 74
Middle Frame Step 8 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Left Arm Upper Step 1 Parts Needed 96 mm Channel 5/16" Socket Head Tube Clamp Cap Screw...
Page 90
Left Arm Upper Step 2 Parts Needed Kep Nut 5/16" Socket Head Cap Screw Servo Joint Pivot Bracket...
Page 91
Left Arm Upper Step 3 Parts Needed 1/2" Socket Axle Hub Head Cap Screw...
Page 92
Left Arm Upper Step 4 Parts Needed Kep Nut Gear Hub Spacer Pack 64 x 192 mm Building Plate *Only need to use 2 screws *Flat plate bent around coffee can Nuts & Bolts used in this step are highlighted in YELLOW...
Page 93
Left Arm Upper Step 5 Parts Needed 96 mm Channel Tube Clamp 5/16" Socket Head Cap Screw...
Page 94
Left Arm Upper Step 6 Parts Needed 220 mm Tube 1/2" Socket Head Cap Screw...
Page 96
Left Arm Lower Step 1 Parts Needed 180 Degree Tube Clamp Kep Nut 5/16" Socket Head Servo Horn Cap Screw *Just the metal horn Servo Joint Pivot Bracket...
Page 97
Left Arm Lower Step 2 Parts Needed Pivot Bearing 5/16" Socket 3/8" Button Bracket Pack Head Head Cap Screw Cap Screw Single Servo 180 Degree Servo Kep Nut Motor Bracket *Just the servo Nuts & Bolts used in this step are highlighted in YELLOW...
Right Arm Upper Step 1 Parts Needed 5/16" Socket Head Tube Clamp Kep Nut Cap Screw 96 mm Channel Servo Joint Pivot Bracket...
Page 106
Right Arm Upper Step 2 Parts Needed 1/2" Socket Axle Hub Head Cap Screw...
Page 107
Right Arm Upper Step 3 Parts Needed Kep Nut Gear Hub Spacer Pack 64 x 192 mm Building Plate *Only need to use 2 screws *Flat plate bent around coffee can Nuts & Bolts used in this step are highlighted in YELLOW...
Page 108
Right Arm Upper Step 4 Parts Needed 96 mm Channel Tube Clamp 5/16" Socket Head Cap Screw...
Page 109
Right Arm Upper Step 5 Parts Needed 220 mm Tube 1/2" Socket Head Cap Screw...
Page 111
Right Arm Lower Step 1 Parts Needed 180 Degree Tube Clamp Kep Nut 5/16" Socket Head Servo Horn Cap Screw *Just the metal horn Servo Joint Pivot Bracket...
Page 112
Right Arm Lower Step 2 Parts Needed Pivot Bearing 5/16" Socket 3/8" Button Bracket Pack Head Head Cap Screw Cap Screw Single Servo 180 Degree Servo Kep Nut Motor Bracket *Just the servo Nuts & Bolts used in this step are highlighted in YELLOW...
Page 120
Middle Step 1 Parts Needed HiTechnic Servo 5/16" Socket Head Kep Nut Controller Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 121
Middle Step 1 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 122
Middle Step 2 Parts Needed 1" Stand-Off Post Kep Nut 64 x 192 mm Flat 5/16" Socket 64 x 192 mm Building Building Plate Head Plate *Flat plate bent *Cut down to Cap Screw around coffee can 96 mm...
Page 123
Middle Step 3 Parts Needed 5/16" Socket Head Kep Nut Cap Screw Starting from top, count 5 small holes down. This is where the first bolt of the top armor will be placed. Leave a gap with 1 small hole between each piece of armor.
Page 124
Middle Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 125
Middle Step 3 continued NOTE: THE WIRING SHOULD BE RUN BEFORE THE BOTTOM 2 SETS OF RIBS ARE BOLTED IN.
Page 126
Middle Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 127
Middle Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 160
Head Step 1 Parts Needed Kep Nut 160 mm Channel Gear Hub Spacer Pack *Only need to use 3 screws Single Servo Motor Bracket...
Page 161
Head Step 2 Parts Needed 2" Stand-Off Post 100 mm Axle 80 Tooth Gear Gear Hub Spacer Pack 96 mm Channel Axle Hub 3/8" Axle Spacer 5/16" Socket Head Cap Screw...
Page 164
Head Step 4 Parts Needed Bronze 1/8" Axle Axle Hub Bushing Spacer...
Page 165
Head Step 5 Parts Needed 1/2" Socket Kep Nut 40 Tooth Gear Head Cap Screw 180 Degree Servo & Serv0 Horn...
Page 166
Head Step 6 Parts Needed 1/8" Axle 3/8" Button Kep Nut Spacer Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 167
Head Step 7 Parts Needed 64 x 192 mm Building 64 x 192 mm Flat Bracket 5/16" Socket Kep Nut Plate *Flat plate bent Building Plate Head around coffee can Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 188
Mr. Robot Finish Step 3 Parts Needed 1/2" Socket Kep Nut Head Cap Screw...
Page 189
Mr. Robot Finish Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 190
Mr. Robot Finish Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 191
Mr. Robot Finish Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 192
Mr. Robot Finish Step 3 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 193
Mr. Robot Finish Step 4 Parts Needed 288 mm Channel 1/2" Socket Kep Nut Head Cap Screw Nuts & Bolts used in this step are highlighted in YELLOW...
Page 194
Mr. Robot Finish Step 4 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 195
Mr. Robot Finish Step 4 continued Nuts & Bolts used in this step are highlighted in YELLOW...
Page 196
Mr. Robot Finish Step 4 continued Nuts & Bolts used in this step are highlighted in YELLOW...
