Left Leg Step 1
Parts Needed
12x
1x
1x
Kep Nut
416 mm Channel
160 mm Channel
2x
12x
288 mm Channel
1/2" Socket
Head Cap Screw
Cutaway section on 288 mm
Channel is only illustrated to
show detail. This part is not
meant to be cut.
Nuts & Bolts used in this step
are highlighted in YELLOW
