Instructions
™
G3 SP
Lubrication Pump
For dispensing of NLGI Grades #000 to #2 greases. For Professional Use Only.
Not approved for use in explosive atmospheres or hazardous locations.
Part Nos., page 3
5100 psi (35.1 MPa, 351.6 bar) Pump Output Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save all instructions.
Automatic
Conforms to ANSI/UL 73
Certified to CAN/CSA
Std. 22.2 No 68-09
3132066
24V and 110-240VAC Pumps ONLY
3A4676B
EN
