Installation Instructions-Tubular Monolithic Entry Set - Dummy
2 - 3 / 8 "
o r
2 - 3 / 4 "
*
5 - 1 /2 "
2 - 1 / 8 " D ia .
B o r e s
*
Marietta 6 style locks have 6" center
to center bore spacing.
Installation Instructions-Tubular Sectional Entry Set - Dummy
2-3/8"
or
2-3/4"
No less
than
4-1/2"
2-1/8" D ia.
Bores
Optional Dead
Bolt Collar
For Brass Only
IMPORTANT:
Do not remove screws
Optional Dead
Bolt Collar
For Brass Only
AFTER LOCK HAS BEEN INSTALLED
Tighten Set Screws with Allen Wrench
AFTER LOCK HAS BEEN INSTALLED
Tighten Set Screws with Allen Wrench
IN4-ENTSETDUMY
REV. 03/26/08
