Valve terminal type MPA
MPA pneumatics
manual
Valve terminal with
MPA pneumatics
Type:
MPA1−MP−...,
MPA...−MPM−... and
MPA...−FB−...
Manual
534 241
en 0502b
[681 970]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPA1-MP Series and is the answer not in the manual?

Questions and answers

Related Manuals for Festo MPA1-MP Series

Summary of Contents for Festo MPA1-MP Series

  • Page 1 Valve terminal type MPA MPA pneumatics manual Valve terminal with MPA pneumatics Type: MPA1−MP−..., MPA...−MPM−... and MPA...−FB−... Manual 534 241 en 0502b [681 970]...
  • Page 3 ....... . . 534 241 E (Festo AG & Co. KG, D 73726 Esslingen, Federal Republic of Germany, 2005) Internet: http://www.festo.com...
  • Page 4 Contents and general instructions Festo P.BE−MPA−EN en 0502b...

  • Page 5: Table Of Contents

    3−20 3.3.5 Connecting the electric cables ......3−23 Festo P.BE−MPA−EN en 0502b...
  • Page 6 ........5−39 Festo P.BE−MPA−EN en 0502b...
  • Page 7 ............C−1 Festo P.BE−MPA−EN en 0502b...
  • Page 8 Contents and general instructions Festo P.BE−MPA−EN en 0502b...

  • Page 9: Designated Use

    National and local safety regulations must also be observed. Target group This manual is directed exclusively at technicians trained in control and automation technology. Service Please consult your local Festo repair service if you have any technical problems. Festo P.BE−MPA−EN en 0502b...

  • Page 10: Notes On This Manual

    The following table provides an overview. with MP connection Information on the electric/electronic components: see leaflet with product Table. 0/1: Connection variants of the MPA valve terminal VIII Festo P.BE−MPA−EN en 0502b...
  • Page 11 CPX−... Table. 0/2: Manuals on the MPA valve terminal with CPX terminal Festo P.BE−MPA−EN en 0502b...
  • Page 12 Fig. 0/1: Main components of the MPA valve terminal This manual contains the documentation for the valve plates with Ident.code B, D, E, G, H, J, K, M, N, W and X (see chapter "System overview, Description of components"). Festo P.BE−MPA−EN en 0502b...

  • Page 13: Important User Instructions

    ... This means that failure to observe this instruction may result in damage to property. The following pictogram marks passages in the text which describe activities with electrostatically sensitive compo nents. Electrostatically sensitive components: These components may be damaged if they are not handled correctly. Festo P.BE−MPA−EN en 0502b...
  • Page 14 Pictograms Information: Recommendations, tips and references to other sources of information. Accessories: Information on necessary or useful accessories for the Festo product. Environment: Information on environment−friendly use of Festo products. Text markings The bullet indicates activities which may be carried out in ·...
  • Page 15 Base with electric multipin connection and pneumatic connections MPA1 Designation of the MPA valve terminal with 10 mm wide valve plates Modular Performance Sub−base valve terminal (type 32) with MP con Valve terminal type MPA nection or for CPX terminal XIII Festo P.BE−MPA−EN en 0502b...
  • Page 16 Connecting the tubing Connecting the supply lines (tubing) to the MPA valve terminal Supply unit Unit for additional supply of compressed air to the valve plates, e.g. with several pressure zones Table. 0/3: Product−specific terms and abbreviations Festo P.BE−MPA−EN en 0502b...

  • Page 17: Summary Of Components

    Summary of components Chapter 1 1−1 Festo P.BE−MPA−EN en 0502b...
  • Page 18 Description of components ....... . 1−7 1−2 Festo P.BE−MPA−EN en 0502b...
  • Page 19 Information on the modules of the CPX terminal can be found in the CPX system manual. Information on the electronic modules of the MPA valve ter minal can be found in the CPX I/O modules manual. 1−3 Festo P.BE−MPA−EN en 0502b...

  • Page 20: The Mpa Valve Terminal

    1. Summary of components The MPA valve terminal Festo assists you in solving your automation tasks at machine level with MPA valve terminals. The modular structure of the MPA valve terminal enables you to use this valve terminal optimally in your machine or system.

  • Page 21: Overview Of Variants

    MPA2: 2, 4, 6 ... 24 valve locations (only with MPM connec tion) Max. 24 valve coils can be actuated. The electrical connec tion of the valve solenoid coils is made centrally via the multipin plug. 1−5 Festo P.BE−MPA−EN en 0502b...
  • Page 22 MPA2: Valves of size 20 mm This variant of the MPA valve terminal can be fitted with valves of both sizes. The MPA valve terminal with MP connection (type MPA1−MP−...) is available in size MPA1. 1−6 Festo P.BE−MPA−EN en 0502b...

  • Page 23: Description Of Components

    Valve plates or blanking plates Sheet metal seal (optional with pressure zone separation) Exhaust plate or large surface−mounted silencer Further optional CPX modules End plate Fig. 1/3: Components of the MPA valve terminal with CPX terminal 1−7 Festo P.BE−MPA−EN en 0502b...
  • Page 24 Valve plates or blanking plates module with LEDs Supply unit with exhaust plate or large Sheet metal seal (optional with surface−mounted silencer pressure zone separation) Fig. 1/4: MPA valve terminal with MP or MPM connection: 1−8 Festo P.BE−MPA−EN en 0502b...
  • Page 25 2 solenoid coils, the maximum possible number of valve locations will be reduced. Valve locations (for MP connection with fixed linking see also Table 3/6). Table 1/1: Maximum number of valve locations depending on the MPA valve terminal variants 1−9 Festo P.BE−MPA−EN en 0502b...
  • Page 26 Valve plate, 3/2−way, single−solenoid, in basic position open, external pressure supply Valve plate, 3/2−way, single−solenoid, in basic position closed, external pressure supply Table 1/2: Ident. code of the valve plates Further information on the valve plates can be found in Ap pendix B. 1−10 Festo P.BE−MPA−EN en 0502b...
  • Page 27 Supply connections "Operating pres Exhaust connections "Valves" (3/5) sure" (1): Work connections (2, 4) per valve Pilot connection "External auxiliary plate pilot air" (12/14) Fig. 1/5: Pneumatic connecting and operating elements of the MPA valve terminal 1−11 Festo P.BE−MPA−EN en 0502b...
  • Page 28 Field bus connection (bus specific) Power supply connection Two−colour− LEDs Earth/ground connection yellow: Signal status display of the pilot solenoids red: Fault display Fig. 1/6: Electrical connecting and display elements of the MPA valve terminal with CPX terminal 1−12 Festo P.BE−MPA−EN en 0502b...
  • Page 29 Inscription label holder with inscription field for addresses Earth/ground connection Sub−D connection LEDs yellow: Signal status display of the pilot solenoids Fig. 1/7: Electrical connecting and display elements of the MPA valve terminal with MP or MPM connection 1−13 Festo P.BE−MPA−EN en 0502b...
  • Page 30 1. Summary of components 1−14 Festo P.BE−MPA−EN en 0502b...
  • Page 31 Fitting Chapter 2 2−1 Festo P.BE−MPA−EN en 0502b...
  • Page 32 ......2−13 Fitting/removing the manual override cap (optional) ....2−15 2−2 Festo P.BE−MPA−EN en 0502b...

  • Page 33: Fitting

    Information on fitting and dismantling the I/O modules can be found in the manual CPX I/O modules. Information on fitting modules and components ordered at a later stage can be found in the leaflet supplied with the product. 2−3 Festo P.BE−MPA−EN en 0502b...

  • Page 34: General Instructions On Fitting And Dismantling

    Handle all modules and components of the MPA valve ter minal with great care. Please note especially the following: The specified torques must be observed. Electrostatically sensitive components Do not therefore touch any contact surfaces. 2−4 Festo P.BE−MPA−EN en 0502b...

  • Page 35: Fitting Variants

    Table 2/1: Methods of fitting the MPA valve terminal Please note Fit the MPA valve terminal so that there is sufficient space for heat dissipation and ensure that the maximum limits for temperatures are observed (see Technical specifica tions"). 2−5 Festo P.BE−MPA−EN en 0502b...

  • Page 36: Hat Rail Fitting/Removal

    MPA valve terminal with MP connection: CPA−BG−NRH This kit consists of 2 M4x10 screws and 2 clamping el ements. for MPA valve terminals with CPX terminal: CPX−CPA−BG− NRH. This kit consists of 3 M4x10 screws and 3 clamping elements. 2−6 Festo P.BE−MPA−EN en 0502b...
  • Page 37 7.5 mm). Make sure there is sufficient space for connecting the cables and the compressed air supply tubing. 3. Fasten the hat rail to the fastening surface at intervals of approx. every 100 mm. 2−7 Festo P.BE−MPA−EN en 0502b...
  • Page 38 Ô Ô Ô Ô Fig. 2/1: Fitting the MPA valve terminal onto a hat rail 7. Fasten the MPA valve terminal, as with the CPX terminal, against tilting or sliding by tightening the locking screw with 1.3 Nm. 2−8 Festo P.BE−MPA−EN en 0502b...
  • Page 39 2. Swing the MPA valve terminal forwards away from the hat rail (see Fig. 2/3). 3. Lift the MPA valve terminal away from the hat rail (see Fig. 2/3). 2−9 Festo P.BE−MPA−EN en 0502b...

  • Page 40: Fitting Onto / Removing From A Wall

    Fig. 2/3: Dismantling the MPA valve terminal 2.2.2 Fitting onto / removing from a wall The end plates, the MP sub−base or pneumatic interface con tain holes for fitting the terminal onto a wall (see Table 2/3). 2−10 Festo P.BE−MPA−EN en 0502b...
  • Page 41 Make sure there is sufficient space for connecting the power cables and compressed air tubing. 2. Drill mounting holes in the fastening surface. 3. Fasten the MPA valve terminal with M4 or M6 screws of sufficient length to the fastening surface. 2−11 Festo P.BE−MPA−EN en 0502b...
  • Page 42 1. Prevent a hanging−mounted MPA valve terminal from fal ling down before you loosen it from the fastening surface. 2. Loosen the fastening screws (see Table 2/3). 3. Remove the MPA valve terminal from the fastening surface. 2−12 Festo P.BE−MPA−EN en 0502b...

  • Page 43: Fitting/Removing The Inscription Label Holders

    Proceed as follows: Clip the inscription label holders into the grooves in the · sub−bases (see diagram): Recess for the inscription label holder in the sub−base Inscription label holder Fig. 2/4: Fitting the inscription label holder 2−13 Festo P.BE−MPA−EN en 0502b...
  • Page 44 (blade width max. 3.5 mm) to press down the snap hook (see diagram). Holes for unlocking the inscription label holder Inscription label holder Fig. 2/5: Removing the inscription label holder 3. Pull the inscription label holder out of the recess in the sub−base. 2−14 Festo P.BE−MPA−EN en 0502b...

  • Page 45: Fitting/Removing The Manual Override Cap (Optional)

    (see chapter 4, Table 4/5). 2. Clip the manual override caps into the grooves in the manual overrides (see diagram): Manual override Manual override Fig. 2/6: Fitting the manual override caps 2−15 Festo P.BE−MPA−EN en 0502b...
  • Page 46 2. Fitting Removing Proceed as follows: Use a suitable screwdriver to lift the manual override caps · out of the manual overrides (see diagram): Fig. 2/7: Removing the manual override caps 2−16 Festo P.BE−MPA−EN en 0502b...

  • Page 47: Installation

    Installation Chapter 3 3−1 Festo P.BE−MPA−EN en 0502b...
  • Page 48 ... 3−27 3.4.3 MPA valve terminal with MPM connection ....3−29 3−2 Festo P.BE−MPA−EN en 0502b...
  • Page 49 I/O modules etc.) can be found in the relevant manuals for the CPX module. Detailed instructions on addressing the pneumatic modules of the MPA valve terminal with CPX terminal can be found in the "Manual for the CPX I/O modules." 3−3 Festo P.BE−MPA−EN en 0502b...

  • Page 50: Installation

    If possible, operate your system with non−lubricated com pressed air. This will prevent pollution of the environment. Festo pneumatic valves and actuators have been designed so that, if used as intended, they will not require additional lu brication and will still achieve a long service life.
  • Page 51 Incorrect additional oil and too much residual oil content in the compressed air will reduce the service life of the valve terminal. Use Festo special oil OFSW−32 or the other oils listed in the Festo catalogue (as per DIN 51524−HLP32, basic viscosity 32cST at 40 °C).
  • Page 52 A further indication of excessive lubrication is the colouring or status of the exhaust silencer. A distinctly yellow colouring of the filter element or drops of oil on the silencer indicate that the lubricator setting is too high. 3−6 Festo P.BE−MPA−EN en 0502b...

  • Page 53: General Notes On Connecting The Tubing

    2. Pull the locking ring 1 over the tube connection or tighten the locking screw2 . 3. For reasons of clarity, group the tubing together with: tube straps or multiple hose holders 3−7 Festo P.BE−MPA−EN en 0502b...
  • Page 54 1. Mark all pneumatic tubing. 2. Press the locking ring of the screw connector 1 e.g. with a screwdriver or the loosening tool QSO from Festo or loosen the locking screw 2 of the screw connector. 3. Remove the tubing from the screw connector.
  • Page 55 3. Installation Fig. 3/2: Disconnecting the tubing 3−9 Festo P.BE−MPA−EN en 0502b...

  • Page 56: Connecting The Mpa Valve Terminal

    MPA valve terminal with MP or MPM connection: on the MP or MPM sub−base if necessary, on the supply unit next to the right−hand end plate 3−10 Festo P.BE−MPA−EN en 0502b...

  • Page 57: Pilot Control Of The Valve Solenoid Coils (Auxiliary Pilot Air)

    If the operating pressure lies below 3 bar or above 8 bar, pilot control of the valve solenoid coils must be operated with ex ternal auxiliary pilot air. In this case, the auxiliary pilot air is supplied externally via pilot connection 12/14. 3−11 Festo P.BE−MPA−EN en 0502b...

  • Page 58: Mpa Valve Terminal With Pressure Zone Separation

    On the sub−bases with pressure zone separation only supply channel (1) is separate. Separation is made in the centre of the sub−base, i.e. on the MPA1 after the second valve location the MPA2 after the first valve location. 3−12 Festo P.BE−MPA−EN en 0502b...
  • Page 59 3 ... 8 bar. You can recognize whether your MPA valve terminal is equipped with pressure zones either by the marking on the sub−base (see Table 3/3) or by the marking on the seal (see Table 3/4). 3−13 Festo P.BE−MPA−EN en 0502b...
  • Page 60 3. Installation MPA1 MPA2 Type: MPA1−FB−AP−T1 Type: MPA2−FB−AP−T0 Table 3/3: Sub−bases with pressure zone separation 3−14 Festo P.BE−MPA−EN en 0502b...
  • Page 61 Table 3/4: Sub−base seals, identification of the seal variants The following diagrams show as an example the assignment of the supply and exhaust connections to the valve plates on an MPA valve terminal with blocked channels 1, 3 and 5. 3−15 Festo P.BE−MPA−EN en 0502b...
  • Page 62 (e.g. of neighbouring pressure zones) must not lie next to each other. By fitting an additional supply unit within a pressure zone you can supply additional supply air or extract exhaust air. 3−16 Festo P.BE−MPA−EN en 0502b...
  • Page 63 Identification of the pressure zone dividing seal (projecting flag) Pressure zone 1 Supply unit for pressure zone 2 Pressure zone 2 Fig. 3/3: Example of MPA valve terminal with CPX terminal and 3 pressure zones 3−17 Festo P.BE−MPA−EN en 0502b...
  • Page 64 Ö Ö Ö Ö Ö MP sub−base Supply unit Pressure zone 1 Identification of the pressure zone dividing seal (projecting flag) Pressure zone 2 Fig. 3/4: Example: MPA valve terminal with MP connection and 2 pressure zones 3−18 Festo P.BE−MPA−EN en 0502b...

  • Page 65: Vacuum/Low Pressure Operation

    These valves can be supplied individually and there fore operated in the pressure range − 0.9 ... 10 bar. 5/2−way valve, single−solenoid (Ident. code M) 5/2−way valve, double−solenoid (Ident. code J) 5/3−way valves (Ident. codes B, E and G) 3−19 Festo P.BE−MPA−EN en 0502b...

  • Page 66: Connecting The Pneumatic Tubing

    On MPA valve terminals with exhaust plates, the pilot ex haust is vented on at least one supply unit via connection 82/84. Fit the screw connector or the silencers according to the table below. Then lay the tubing. 3−20 Festo P.BE−MPA−EN en 0502b...
  • Page 67 1) Depending on what you have ordered, the MPA valve terminal may already be fitted with QS screw connectors. 2) Only with MPA valve terminals with exhaust plate or supply unit Table 3/5: Assignment of the connections 3−21 Festo P.BE−MPA−EN en 0502b...
  • Page 68 82/84 in order to prevent functional impairment due to back pressures. First MPA valve terminal common 3/5 central 82/84 central 3/5 Second MPA valve terminal common 82/84 Fig. 3/6: Common lines with non−return valves 3−22 Festo P.BE−MPA−EN en 0502b...

  • Page 69: Connecting The Electric Cables

    I/O modules etc.) can be found in the relevant manuals for the CPX modules. MPA valve terminal with MP or MPM connection: Instructions on connecting the electric cables can be found in the leaflet supplied with the product. 3−23 Festo P.BE−MPA−EN en 0502b...
  • Page 70 Fig. 3/7: Earthing the MPA valve terminal Detailed instructions on the earthing measures to be under taken on the MPA valve terminals with CPX terminal can be found in chapter 3 in the CPX system manual. 3−24 Festo P.BE−MPA−EN en 0502b...

  • Page 71: Address Assignmentof The Valves

    Counting begins on the valve terminal from left to right Each valve location occupies 2 addresses, irrespective of the valve plate or blanking plate fitted. The following assignment applies: Solenoid coil 14 occupies the lower−value address, solenoid coil 12 occupies the higher−value address. 3−25 Festo P.BE−MPA−EN en 0502b...
  • Page 72 Fig. 3/8: Example: Address assignment of an MPA valve terminal with CPX terminal and 6 valve locations (top view) Further instructions on addressing the pneumatic modules of the MPA valve terminal with CPX terminal can be found in the manual for the CPX I/O modules. 3−26 Festo P.BE−MPA−EN en 0502b...

  • Page 73: Mpa Valve Terminal With Mp Connection (Only Mpa1)

    1) Two solenoid coils per valve location can be controlled. 2) One solenoid coil per valve location can be controlled. Table 3/6: Address assignment of the MPA valve terminal with MP connection (only MPA1) type MPA1−MP−... 3−27 Festo P.BE−MPA−EN en 0502b...
  • Page 74 Addresses of coils 14 Valve plates on valve locations which occupy one address each. Fig. 3/9: Example: Address assignment of the MPA valve terminal with MP connection and 16 valve locations, type MPA1−MP−... (top view) 3−28 Festo P.BE−MPA−EN en 0502b...

  • Page 75: Mpa Valve Terminal With Mpm Connection

    VMPA1−MPM−EMM−8 VMPA2−MPM−EMM−4 Table 3/7: Electronic module for MPM connection If an electronic module occupies 2 addresses, the follow ing applies: pilot solenoid 14 occupies the lower−value address; pilot solenoid 12 occupies the higher−value address. 3−29 Festo P.BE−MPA−EN en 0502b...
  • Page 76 Electronic 1 VMPA1−MPM−EMM−8 1 VMPA2−MPM−EMM−4 module 1 VMPA1−MPM−EMM−4 1 VMPA2−MPM−EMM−2 For controlling the valves, each valve solenoid coil (referred to in the following as coil) is assigned to a certain pin of the multipin plug. 3−30 Festo P.BE−MPA−EN en 0502b...
  • Page 77 1) Connect 0 V with positive−switching control signals, 24 V with negative−switching control signals; mixed operation is not permitted. Table 3/8: Example: Address assignment of the MPA valve terminal with MPM connection and 12 valve loca tions 3−31 Festo P.BE−MPA−EN en 0502b...
  • Page 78 VMPA1−MPM−EMS−8 occupies two VMPA2−MPM−EMS−−4 occupies two addresses per valve location addresses per valve location Fig. 3/10: Example: Address assignment of the MPA valve terminal with MPM connection and 12 valve locations, type MPA...−MPM−... (top view) 3−32 Festo P.BE−MPA−EN en 0502b...

  • Page 79: Commissioning

    Commissioning Chapter 4 4−1 Festo P.BE−MPA−EN en 0502b...
  • Page 80 ........4−16 4.5.2 Operating states of the pneumatic system ....4−17 4−2 Festo P.BE−MPA−EN en 0502b...
  • Page 81 LEDs and manual override to the valve solenoid coils function impairments operating states of the pneumatic system Further information Commissioning the CPX terminal is described in the appropri ate manual for the CPX field bus node. 4−3 Festo P.BE−MPA−EN en 0502b...

  • Page 82: Commissioning

    This can cause damage to the machine or system and even injury to human beings. Operate the valve terminal with external auxiliary pilot · air (3 ... 8 bar). Branch the auxiliary pilot air in front of the safety start−up valve (see diagram). 4−4 Festo P.BE−MPA−EN en 0502b...
  • Page 83 Externally supplied auxiliary pilot air (3 to 8 bar), branched in front of the safety start−up valve Safety start−up valve (slow build up of pressure of complete supply) Fig. 4/1: Example of valve−cylinder combination with slow increase in pressure of the complete supply 4−5 Festo P.BE−MPA−EN en 0502b...

  • Page 84: Manual Override

    After actuation the manual over ride is reset automatically by a spring. manual override locking The manual override remains ac tuated until it is reset by hand. Table 4/2: Actuation methods of the manual override 4−6 Festo P.BE−MPA−EN en 0502b...
  • Page 85 Manual override for valve solenoid Valve size MPA2 coils 12 Valve size MPA1 Manual override for valve solenoid coils 14 Fig. 4/2: Position of the manual overrides (top view) 4−7 Festo P.BE−MPA−EN en 0502b...

  • Page 86: Checking The Valves And The Valve−Actuator Combination

    Table 4/3: Commissioning variants How to commission the pneumatic components by means of the manual override is described below. Commissioning of the CPX terminal is described in the ap propriate manual for the CPX field bus node. 4−8 Festo P.BE−MPA−EN en 0502b...
  • Page 87 A valve which has been switched by an electric signal, can not be reset by the manual override. The electric signal is dominant in this case. Reset the electric signal before actuating the manual · override. 1. Switch on the compressed air supply. 4−9 Festo P.BE−MPA−EN en 0502b...
  • Page 88 When the manual override is actuated, it is not possible to reset the valve to its basic position with an electric signal. The manual override is dominant in this case. 4. Switch off the compressed air supply after checking the valves. 4−10 Festo P.BE−MPA−EN en 0502b...
  • Page 89 Release the plunger (the spring moves back to the basic position · resets the plunger of the manual (not with double−solenoid valve, override to the basic position). Ident. code J) Table 4/4: Operating the non−locking manual override 4−11 Festo P.BE−MPA−EN en 0502b...
  • Page 90 Then turn the plunger in an anti− moves back to the basic position · clockwise direction as far as poss (not with double−solenoid valve, ible. Ident. code J) Then release the plunger. · Table 4/5: Locking actuation of the manual override 4−12 Festo P.BE−MPA−EN en 0502b...

  • Page 91: Led Display Of The Valves

    LED and manual override for valve Valve size MPA2 solenoid coil 12 Valve size MPA1 LED and manual override for valve solenoid coil 14 Fig. 4/3: Assignment of LEDs and manual override to the valve solenoid coils 4−13 Festo P.BE−MPA−EN en 0502b...
  • Page 92 CPX I/O modules) Table 4/6: Meaning of the LED display (MPA valve terminal with CPX terminal) Further instructions on commissioning and diagnosing the MPA pneumatic modules can be found in the manual for the CPX I/O modules. 4−14 Festo P.BE−MPA−EN en 0502b...
  • Page 93 (18 V ... 30 V DC) Compressed air supply not OK pilot exhaust blocked servicing required Table 4/7: Meaning of the LED display (MPA valve terminal with MP or MPM connection) 4−15 Festo P.BE−MPA−EN en 0502b...

  • Page 94: Eliminating Faults

    (if necessary set as a factor of the operat ing pressure, see chapter 3) servicing required · Table 4/8: Function impairment of the pneumatic system 4−16 Festo P.BE−MPA−EN en 0502b...

  • Page 95: Operating States Of The Pneumatic System

    MPA valve terminal Slow start−up after If there are control signals, the auxi EMERGENCY STOP liary pilot air must have a pressure of 3 ... 3...10 bar immediately after being switched on Table 4/9: Pneumatic operating states 4−17 Festo P.BE−MPA−EN en 0502b...
  • Page 96 4. Commissioning 4−18 Festo P.BE−MPA−EN en 0502b...

  • Page 97: Diagnosis And Error Treatment

    Diagnosis and error treatment Chapter 5 5−1 Festo P.BE−MPA−EN en 0502b...
  • Page 98 ........5−39 5−2 Festo P.BE−MPA−EN en 0502b...

  • Page 99: Diagnosis And Error Treatment

    Information on fitting /removing components and on the elec trical connections can be found in the CPX system manual. MPA valve terminal with multipin connection: Instructions on connecting the electric components can be found in the leaflet supplied with the product. 5−3 Festo P.BE−MPA−EN en 0502b...

  • Page 100: General Precautionary Measures

    Screw connections must be fitted free of offset and · mechanical tension. Check the seals for damage (IP 65). · The contact surfaces must be dry and clean (sealing · effect, avoid leakage and contact faults). 5−4 Festo P.BE−MPA−EN en 0502b...

  • Page 101: Dismantling The Mpa Valve Terminal

    Loosening the pneumatic connections The procedure for loosening the penumatic connections is described in chapter 3. Dismantling the MPA valve terminal The procedure for dismantling the MPA valve terminal is de scribed in chapter 2. 5−5 Festo P.BE−MPA−EN en 0502b...

  • Page 102: Servicing The Mpa Valve Terminal

    3. Check the seal between the basis component and the surface mounted silencer for damage. Replace the seal if it is damaged. 4. Fasten the silencer only with the original screws. Tighten the screws in diagonally opposite sequence with 1.0 Nm. 5−6 Festo P.BE−MPA−EN en 0502b...

  • Page 103: Fitting/Removing The Large Surface Mounted Silencer Or The Exhaust Plate

    The sub−bases of the MPA valve terminal with MPM con nection (modular linking) support the control of one or two solenoid coils per valve location depending on the MPA electronic module fitted (see Table 5/5). Dismantling Proceed as follows: 5−7 Festo P.BE−MPA−EN en 0502b...
  • Page 104 The conical ring seals between the electronic module and the component must be fitted on the guide pin of the component so that the cone points in the direction of the electronic module and slides easily into the ap 5−8 Festo P.BE−MPA−EN en 0502b...
  • Page 105 Valve plate or blanking plate Cord seal 2 conical seals per valve plate or blanking plate (observe the alignment) Sub−base Electronic module Fig. 5/2: Fitting valve plates or blanking plates (MPA1) 5−9 Festo P.BE−MPA−EN en 0502b...
  • Page 106 Fig. 5/3: Fitting valve plates or blanking plates (MPA2) 4. Place the component on the sub−base. 5. Screw the component at first only slightly and then tighten with the following torque: MPA1: 0.25 Nm (±20%) MPA2: 0.65 Nm (±20%) 5−10 Festo P.BE−MPA−EN en 0502b...

  • Page 107: Replacing Electronic Modules

    Discharge yourself electrostatically before fitting or re · moving components in order to protect the components against discharges of static electricity. Caution Replace an electronic module only by an electronic module of the same type. 5−11 Festo P.BE−MPA−EN en 0502b...
  • Page 108 FB−EMG−... Vel/sen and Vval are completely electrically isola ted. In conjunction with an interlinking block with valve sup ply type CPX−GE−EV−V, it is therefore possible to switch off the valve supply voltage at all poles. 5−12 Festo P.BE−MPA−EN en 0502b...
  • Page 109 Further information on MPA electronic modules can be found in the "Electronics Manual for the CPX I/O modules" (P.BE− CPX−EA−..) and in the information supplied with the product. 5−13 Festo P.BE−MPA−EN en 0502b...
  • Page 110 Type VMPA1−MP−EMS−4: −−− Electronic module with 4 outputs One valve solenoid coil can be controlled per valve location. Table 5/4: Electronic modules for the MPA valve terminal (size MPA1) with MP connection (type MPA1−MP−...) 5−14 Festo P.BE−MPA−EN en 0502b...
  • Page 111 (see section "Removing valve plates or blanking plates"). 1. Loosen the screws with which the electronic module is fastened to the sub−base. 2. Pull the electronic module upwards out of the body of the sub−base. 5−15 Festo P.BE−MPA−EN en 0502b...

  • Page 112: Replacing The Sub−Base, Supply Unit Or Mpa End Plate

    (valve plates, blanking plates and electronic modules) from all sub−bases. 3. Loosen the screws of the component (sub−base, supply unit or end plate) which you wish to remove in the se quence 3 2 1 (see diagram). 5−16 Festo P.BE−MPA−EN en 0502b...
  • Page 113 Ö Ö Ö Ö Ö Ö Ö Ö Ö Ö Fig. 5/4: Position of the screw connectors of the sub−bases and of the right−hand end plate 5. Pull the relevant component away from the neighbouring component. 5−17 Festo P.BE−MPA−EN en 0502b...
  • Page 114 2. Place the sheet metal seal onto the guide pin of the sub− base or supply unit. Guide pins Sheet metal seal (optional with pressure zone separation) Fig. 5/5: Fitting the sub−base 5−18 Festo P.BE−MPA−EN en 0502b...
  • Page 115 4. Mount the MPA valve terminal on the fastening surface (see chapter 2 "Fitting onto a wall" or "Fitting onto a hat rail"). 5. Then fit the pneumatic and electrical connections (see chapter 3 "Installation, connecting the MPA valve ter minal"). 5−19 Festo P.BE−MPA−EN en 0502b...

  • Page 116: Replacing The Manifold Boards

    Board for controlling a total of 4 valve solenoid coils per sub− base. Type: VMPA2−MPM−EV−AB−2 Type: VMPA2−MPM−EV−ABV−2 Only for size MPA2: Board for controlling a total of 2 valve solenoid coils per sub− base. Table 5/6: Manifold boards type VMPA−MP−... 5−20 Festo P.BE−MPA−EN en 0502b...
  • Page 117 Fig. 5/7: Removing the end piece from the last manifold board 5. Loosen the relevant manifold board by unlocking the lock ing clip. Then pull the manifold board to the right out of the sub−base. 5−21 Festo P.BE−MPA−EN en 0502b...
  • Page 118 Fig. 5/9: Fitting the manifold board 2. If the last fitted manifold board is the last one in front of the fright−hand MPA end plate, you must insert the end piece type MPA into this manifold board. 5−22 Festo P.BE−MPA−EN en 0502b...
  • Page 119 3. Fit the sub−base to the neighbouring components (see section 5.3.5). 4. Remove the electronic module from the sub−base (see section 5.3.4). 5. Fit all the valve plates and blanking plates again onto the sub−base (see section 5.3.3). 5−23 Festo P.BE−MPA−EN en 0502b...

  • Page 120: Converting The Mpa Valve Terminal

    Mixed operation of the MPA valve terminal with internal and external pilot air is not intended. Irrespective of the available pressure zones, all valve solenoid coils of the MPA valve terminal are supplied with the same pilot air. 5−24 Festo P.BE−MPA−EN en 0502b...
  • Page 121 Pilot control with ex VMPA...−FB−EPL−EU MPA1−MP−EPL−EU / open connection 12/14 ternal pilot air VMPA1−MPM−EPL−EU Large surface−mounted Exhausting via large silencer surface−mounted si lencer Table 5/8: Variants of the pneumatic interface, the MP or MPM sub−base 5−25 Festo P.BE−MPA−EN en 0502b...
  • Page 122 (see this chapter "Dismantling the MPA valve terminal"). 2. Place the MPA valve terminal on a flat working surface. 3. MP connection: Loosen and remove the board with the multipin plug in the MP sub−base (position of the fastening screws see diagram). 5−26 Festo P.BE−MPA−EN en 0502b...
  • Page 123 5. Loosen the fastening screws between the MP or MPM sub−base and the pneumatic sub−bases in the sequence 3 2 1 (see following diagram). 6. Then loosen and remove the fastening screws. 5−27 Festo P.BE−MPA−EN en 0502b...
  • Page 124 5. Diagnosis and error treatment Fig. 5/12: Position of the screw connectors on the sub−base 7. Pull the MP or MPM sub−base away from the neighbour ing sub−bases. 5−28 Festo P.BE−MPA−EN en 0502b...
  • Page 125 Sheet metal seal Pneumatic sub−base Fig. 5/13: Fitting the MP sub−base 3. Push the MP or MPM sub−base together with the pneu matic sub−bases. Make sure that the seal and the compo nents are correctly positioned. 5−29 Festo P.BE−MPA−EN en 0502b...
  • Page 126 1.3 Nm. Fig. 5/14: Screw connectors of the sub−bases 5. MP sub−base: Fit the board with the multipin plug into the MP sub−base. Tighten the screws with 0.9 Nm (± 0.1 Nm) (see diagram). 5−30 Festo P.BE−MPA−EN en 0502b...
  • Page 127 6. Fit the MPA valve terminal onto the fastening surface (see chapter 2 "Fitting onto a wall" or "Fitting onto a hat rail"). 7. Then fit the pneumatic and electrical connections (see chapter 3 "Installation, connecting the MPA valve ter minal"). 5−31 Festo P.BE−MPA−EN en 0502b...

  • Page 128: Converting The Mpa Valve Terminal To Different Pressure Zones

    (3 and 5) You can recognize whether your MPA valve terminal is equipped with pressure zones either by the marking on the sub−base (see Table 5/10) or by the marking on the seal (see Table 5/11). 5−32 Festo P.BE−MPA−EN en 0502b...
  • Page 129 The sheet metal seals for forming pressure zones are di vided into two groups (see following table): sheet metal seals for MPA valve terminals fitted with large surface−mounted silencers sheet metal seals for MPA valve terminals fitted with exhaust plates. 5−33 Festo P.BE−MPA−EN en 0502b...
  • Page 130 Channels 1, 3 and 5 blocked Channels 1, 3 and 5 blocked Channel 1 blocked Channel 1 blocked Channels 3 and 5 blocked Channels 3 and 5 blocked Table 5/11: Sub−base seals, identification of the seal variants 5−34 Festo P.BE−MPA−EN en 0502b...
  • Page 131 2. Place the MPA valve terminal on a flat working surface. 3. Loosen the sub−base at the point where you wish to insert the sheet metal seal for the pressure zone separation (see section "Dismantling sub−bases"). 5−35 Festo P.BE−MPA−EN en 0502b...
  • Page 132 6. Then fit the pneumatic and electrical connections (see chapter 3 "Installation, connecting the MPA valve ter minal"). The following diagram shows the structure of pressure zones using as an example an MPA valve terminal with CPX ter minal. 5−36 Festo P.BE−MPA−EN en 0502b...
  • Page 133 Supply unit with connection 1 for supplying compressed air to the 2nd. pressure zone Pneumatic interface with connection 1 for supplying compressed air to the 1st. pressure zone Fig. 5/16: Example of MPA valve terminal with CPX terminal and 3 pressure zones 5−37 Festo P.BE−MPA−EN en 0502b...
  • Page 134 (see section "Dismantling sub−bases"). Fitting Proceed as follows: 1. Insert the sheet metal seal for the pressure zone separ ation. 2. Fit the sub−base (see section "Fitting sub−bases"). 5−38 Festo P.BE−MPA−EN en 0502b...

  • Page 135: Adding Valve Locations

    You can easily adapt the MPA valve terminal with CPX terminal or with MPM connection to the demands of your machine or system by adding valve locations. The smallest extension unit is a sub−base with 4 valve loca tions (MPA1) or 2 valve locations (MPA2). 5−39 Festo P.BE−MPA−EN en 0502b...
  • Page 136 With 24 controllable solenoid coils the maximum number of sub−bases (X can be calculated as follows: max) MPA valve terminal with CPX terminal Please note Maximum 8 MPA sub−bases are permitted on the MPA valve terminal with CPX terminal. 5−40 Festo P.BE−MPA−EN en 0502b...
  • Page 137 3. MPA valve terminal with MPM connection:If you wish to fit a further sub−base after the last sub−base in front of the right−hand MPA end plate, you must remove the end piece type MPA from the last manifold board. 5−41 Festo P.BE−MPA−EN en 0502b...
  • Page 138 3 "Installation, connecting the MPA valve ter minal"). Please note If a sub−base is inserted between existing sub−bases, the address assignment of all the valves to the right of the inserted sub−base will be shifted. 5−42 Festo P.BE−MPA−EN en 0502b...
  • Page 139 Technical appendix Appendix A A−1 Festo P.BE−MPA−EN en 0502b...

  • Page 140: Technical Appendix

    ..........A−12 A−2 Festo P.BE−MPA−EN en 0502b...

  • Page 141: Technical Specifications

    Operation − 5 ... + 50 Medium − 5 ... + 50 Protection class as per EN 60 529 IP 65 (with cable from Festo accessories) Relative humidity 90 % at 40 Protection against corrosion KBK1 (as per FN940070) Mounting position...
  • Page 142 MPA valve terminal with CPX terminal or with MPM connec tion: If the terminal is fitted on a wall and has 7 or more sub− bases, additional fastenings (wall backets) must be fitted after every 2 to max. 4 sub−bases. A−4 Festo P.BE−MPA−EN en 0502b...
  • Page 143 0.35 mm path at 10−60 Hz; ±30 g at 11 ms duration; −−−−− 5 g acceleration at 60−150 Hz 5 shocks in each direction Table A/3: Values for vibration and shock as per DIN/IEC68 A−5 Festo P.BE−MPA−EN en 0502b...
  • Page 144 Valve location Ident. code D, H, K and N at connection 1: 3 ... 10 bar All valve plates: at connection 12/14: see relevant diagrams Manual override locking or non−locking Table A/4: Medium and pressure range A−6 Festo P.BE−MPA−EN en 0502b...
  • Page 145 1 [bar] Fig. A/2: Diagram: Required pilot pressure related to the operating pressure with exter nal pilot air and use of valve plates with Ident. code M, J; B, E, G, W and X A−7 Festo P.BE−MPA−EN en 0502b...
  • Page 146 5/2−way, double−solenoid −−− B, G, E 5/3−way 1) I.C. = Identification code of the valve plate 2) Values for the mid−position are quoted in brackets Table A/5: Rated flows and valve switching times for MPA1 A−8 Festo P.BE−MPA−EN en 0502b...
  • Page 147 11 / 24 5/3−way, exhausted 11 / 25 1) I.C. = Identification code of the valve plate 2) Values for the mid−position are quoted in brackets Table A/6: Rated flows and valve switching times for MPA2 A−9 Festo P.BE−MPA−EN en 0502b...
  • Page 148 20 mA after 50 ms Table A/8: Technical specifications on electric components, MPA valve terminal with MPM connection Technical specifications on the electric components of the MPA valve terminal with MP or MPM connection are enclosed with the product. A−10 Festo P.BE−MPA−EN en 0502b...
  • Page 149 Table A/9: Technical specifications on electric components, MPA valve terminal with CPX terminal Technical specifications for the electronic module of the MPA valve terminal with CPX terminal can be found in the manual for the CPX I/O modules. A−11 Festo P.BE−MPA−EN en 0502b...

  • Page 150: Festo Accessories

    8 ... 24 valve locations, suitable as drag chain VMPA−KMS2−24−...−PUR Multipin plug without cable VMPA−KMS−H Hat rail fitting kit CPA−BG−NRH MPA valve terminal with CPX terminal Hat rail fitting kit CPX−CPA−BG−NRH Table A/10: Accessories for the MPA valve terminal A−12 Festo P.BE−MPA−EN en 0502b...
  • Page 151 Accessories Appendix B B−1 Festo P.BE−MPA−EN en 0502b...

  • Page 152: Accessories

    ......... B−3 Separating the MPA valve terminal from the CPX terminal ....B−7 B−2 Festo P.BE−MPA−EN en 0502b...

  • Page 153: Overview Of Valve Plates

    Table B/1: Valve plates with 2/2-way valves Valve plates with 3/2-way valves Ident. code: K 82/84 Function: – Two single-solenoid 3/2-way valves, basic position closed 12/14 Ident. code: N 82/84 Function: – Two single-solenoid 3/2-way valves, basic position open 12/14 Festo P.BE-MPA-EN en 0502b...
  • Page 154 Number of assigned outputs on an MPA valve terminal with MP connection (type MPA1-MP-...): The number of outputs, which are assigned to 12/14 this valve, depends on the valve location (see table 3/3). Table B/2: Valve plates with 3/2-way valves Festo P.BE-MPA-EN en 0502b...
  • Page 155 The number of outputs, which are assigned to this valve, depends on the valve location (see 12/14 table 3/3). Ident. code: J 82/84 Function: One 5/2−way valve, double−solenoid 12/14 Table B/3: Valve plates with 5/2−way valves B−5 Festo P.BE−MPA−EN en 0502b...
  • Page 156 5/3−way valve, mid position pressurized 12/14 Ident. code: G 82/84 Function: 5/3−way valve in mid−position blocked 12/14 5 Ident. code: E 82/84 Function: 5/3−way valve, in mid position exhausted 12/14 Table B/4: Valve plates with 5/3−way valves B−6 Festo P.BE−MPA−EN en 0502b...

  • Page 157: Separating The Mpa Valve Terminal From The Cpx Terminal

    (see chapter 5, "Dismantling the MPA valve terminal"). 2. Loosen the fastening screws between the pneumatic inter face and the MPA sub−base in the sequence 3 2 1 (see Fig. B/2). 3. Then loosen the fastening screws. B−7 Festo P.BE−MPA−EN en 0502b...
  • Page 158 B. Accessories Fig. B/2: Removing the MPA valve terminal from the pneu matic interface Information on replacing the pneumatic interface can be found in the CPX system manual. B−8 Festo P.BE−MPA−EN en 0502b...
  • Page 159 Sheet metal seal Pneumatic interface Fig. B/3: Fitting the MPA valve terminal to the pneumatic interface 3. Push the pneumatic interface together with the pneumatic sub−bases. Make sure that the seal and the components are correctly positioned. B−9 Festo P.BE−MPA−EN en 0502b...
  • Page 160 6. Complete the electrical and pneumatic connections of the MPA valve terminal with CPX terminal. Information on this can be found in the electrics section of the CPX system manual in the pneumatics section in chapter 3 of this manual. B−10 Festo P.BE−MPA−EN en 0502b...
  • Page 161 Index Appendix C C−1 Festo P.BE−MPA−EN en 0502b...

  • Page 162: Index

    ............C−1 C−2 Festo P.BE−MPA−EN en 0502b...
  • Page 163 ........3−21 C−3 Festo P.BE−MPA−EN en 0502b...
  • Page 164 ........A−8 C−4 Festo P.BE−MPA−EN en 0502b...
  • Page 165 ........A−4 Medium, Requirements ..... . . 3−4 , A−6 C−5 Festo P.BE−MPA−EN en 0502b...
  • Page 166 ........3−15 C−6 Festo P.BE−MPA−EN en 0502b...
  • Page 167 User instructions ........C−7 Festo P.BE−MPA−EN en 0502b...
  • Page 168 ......A−5 Weights, Components ......A−4 C−8 Festo P.BE−MPA−EN en 0502b...

This manual is also suitable for:

Mpa-fb seriesMpa-mpm series

Table of Contents
