BZB Gear BZ-SC-51UHD User Manual

4k 5x1 multi-format scaler switcher
Hide thumbs

Advertisement

Quick Links

Download this manual
BZ-SC-51UHD
4K 5x1 Multi-format
Scaler Switcher

Advertisement

loading
Need help?

Need help?

Do you have a question about the BZ-SC-51UHD and is the answer not in the manual?

Questions and answers

Related Manuals for BZB Gear BZ-SC-51UHD

Summary of Contents for BZB Gear BZ-SC-51UHD

  • Page 1 BZ-SC-51UHD 4K 5x1 Multi-format Scaler Switcher...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.

  • Page 3: Introduction

    1. Introduction The BZ-SC-51UHD Multi-inputs with HDMI output scaler box supports 5 inputs of 4xHDMI and 1xVGA (YPbPr, CVBS). The input source is capable to switch and scale to adopt resolution then transmit over HDMI output. The HDTV resolution is achievable. The system could be controlled and configure by easily operation of panel button, IR remote and RS-232.

  • Page 4: Package Contents

    3. Package Contents  1x Multi-format Scaler Switcher  2x Mounting ears  1x Remote Control Unit  1x IR Receiver Cable  1x 12V/1A Power Adapter  1x 3RCA(Female) to D-SUB(Male) Cable  1x 3.5mm jack (Male) to 2RCA(Female) Cable ...
  • Page 5 Human body model — ±8kV (air-gap discharge) & ±4kV (contact ESD Protection discharge) Connections 4x HDMI Type A [19-pin female] Input ports 1x VGA [female] 1x Micro USB [5-pin female], optional for Power Supply 1x HDMI Type A [19-pin female] Output ports 1x3.5mm mini jack 1x IR in...

  • Page 6: Operation Controls And Functions

    5. Operation Controls and Functions 5.1 Front Panel Power button and indicator: Switches between standby and work mode. When this device is switched to the standby mode, the indicator turns red. When switching to work mode, the indicator turns blue. IR Window: Receiving IR signal from remote control unit which come with scaler switcher.
  • Page 7 Output: Connect to an HDMI display or AV Receiver for video and audio output. Connect the L/R stereo audio output to the analog audio input port of your amplifier. Input: The input ports include 4 HDMI & 1 VGA input ports. The VGA ports supports YPbPr, C-video and VGA input formats.
  • Page 8 5.3.2 Picture The user can adjust picture contrast (default:50), brightness (default: 50), color (default: 30), sharpness (default: 10), etc. 5.3.3. Aspect Ratio The user can adjust picture output aspect ratio to 4:3 or 16:9.
  • Page 9 5.3.4 Screen The screen MENU adjust for VGA input only. The user can adjust horizontal, vertical position, size and phase. 5.3.5 EDID The EDID adjust MENU for HDMI input only. EDID1.4 for HDMI1.4 standard. EDID2.0 for HDMI2.0 Stardard, and EDID AUTO for copy the display EDID Mode.
  • Page 10 5.3.6 Software update The scaler switcher supports software updates via USB flash disk. The procedure is as follows: 1) Copy the file “MERGE.bin” to the root directory of a USB flash disk. (Make sure the file is copied to the root directory.
  • Page 11 5.3.7 Resolution The scaler switcher HDMI output resolutions support multiple modes. Press the “RES” button on the IR remote, the resolution menu will display. The user can select suitable resolution for HDTV or monitor. Auto means that the HDMI resolutions based on the EDID information read from the display device.
  • Page 12 ④ Press these buttons for select the input sources. ⑤ Press this button for select HDMI output resolution. (Press and hold 5 seconds or more, the HDMI output resolution will reset to 720p60Hz.) ⑥ Menu operation buttons: MENU: press to enter in OSD menu. EXIT: press to exit OSD menu.
  • Page 13 detected to the output. Notice: Auto-switching function works only when there is a new input signal or if an input signal is removed. 5.6 VGA/YPbPr/CVBS input The VGA input port is a multiple format port. It is compliant with VGA/YPbPr/CVBS input signal. The scaler switcher will auto detect the input signal type and format.

  • Page 15: Connection Diagram

    6. Connection Diagram 1. Connect HDMI source devices (e.g. Blu-ray DVD) to HDMI input ports of the scaler switcher with HDMI cable. Connect VGA source device (e.g., PC/notebook) to VGA input ports of the scaler switcher with a VGA cable. 2.

  • Page 16: Mission Statement

    We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank. BZB Gear is the solution for small to medium-sized applications requiring the latest professional products in AV.

  • Page 17: Warranty Information

    8. Warranty Information BZB Gear | Second Year Assurance BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage...
