Summary of Contents for Procentec ProfiHub B2FOR+
- Page 1 ProfiHub B2FOR+ / B4FOR+ User manual...
- Page 2 All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of the publisher. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 2/60...
-
Page 3: Important Information
2292 JD WATERINGEN The Netherlands Tel.: +31-(0)174-671800 Fax: +31-(0)174-671801 Email: info@procentec.com Document Updates You can obtain constantly updated information on PROCENTEC products on the Internet at www.procentec.com You can also contact PROCENTEC Customer Support: • by phone at +31-(0)174-671800 •... -
Page 4: Important Notices
HOT HOUSING warning located on the side of the housing. Make sure this warning is visible after wall installation. UL certification demands the warning to be visible during operation. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 4/60... - Page 5 According to UL60950-1, if a copper PROFIBUS cable is used outside, it is required to install surge protection that is suitable for PROFIBUS. To comply with UL certification regulations the ProfiHub B2FOR+ / B4FOR+ is to be used on altitudes under 2000 m. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 5/60...
-
Page 6: Table Of Contents
3.2 Configuring the Diagnostic Device ......................28 3.2.1 Info data (mandatory module) ......................28 3.2.2 Alarm Confirmation ..........................28 3.2.3 Redundant Status ..........................28 3.2.4 Baudrate Status ........................... 29 ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 6/60... - Page 7 Order codes ..............................44 Glossary ................................ 45 Revision History ............................48 Sales offices and Distributors ........................49 Certificates .............................. 54 Notes ............................... 57 About PROCENTEC ..............................59 ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 7/60...
-
Page 8: Product Description
If bus redundancy is enabled, the two rightmost RS485 channels will form a redundant pair. In combination with another ProfiHubHUB, cable redundancy can be realized. Fig. 1 - ProfiHub B4FOR+ ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 8/60... -
Page 9: Product Features
Intelligent Internal Backbone Alarm contact Port 1 and 2 Power supply 1 Power supply 2 Channel 1 to 4 FO Channel 1 Fig. 2 - ProfiHub connections ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 9/60... -
Page 10: Application Areas
Suitable for all DP cables • Conveniently arranged networks • Easy extendable installations • On-board DB9 female connector on each channel for maintenance activities • Cost Savings ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 10/60... - Page 11 Fig. 4 - Because of the isolation and intelligence the ProfiHub provides, it can be used as a barrier for electrically sensitive segments. This keeps the backbone and other Channels clean. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 11/60...
-
Page 12: Channel Structure
1.6 Cable lengths for PROFIBUS DP The cables on the Channels and the Main-Channel must comply with the PROFIBUS DP cable specifications for RS 485 (Fig. 6). ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 12/60... -
Page 13: Cable Types For Profibus Dp
Fig. 7 - PROFIBUS DP cable specifications The ProfiHub B2FOR+ / B4FOR+ can handle cables based on multiple protection sheaths with an overall cable diameter between 6 to 12 mm ( Fig. 8 ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 13/60... -
Page 14: Cable Lengths For Fiber Optic
17 dB Connectors 4 x ST/BFOC (one channel, two ports) Topologies Ring, point-to-point (direct, hub, split, star) Cascading depth No limit, only busparameter limitation of the master ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 14/60... -
Page 15: Status Leds
It can also be that the baudrate is not locked (no PROFIBUS master on the bus). If a baudrate has been locked and the master disappears from the bus, the current baud rate will be unlocked after 50 seconds. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 15/60... -
Page 16: Installation Instructions Profihub B2For+ / B4For
This is to prevent the product to potentially slide off the DIN-rail. See Fig. 9 for an example. Fig. 9 – Rubber studs on backside of housing ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 16/60... -
Page 17: Power Supply
Limited Power Source (LPS) or NEC Class 2 or CEC Class 2 • Voltage: 12 - 24 VDC • Current: min 130 mA • Wire diameter: < 2.5 mm ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 17/60... -
Page 18: Grounding Of The Power
Ground Rail of the ProfiHub. Connect the Ground Rail to the common ground with a separate ground lead. See Fig. 12 for an example. Fig. 12 - Connection to Ground Rail ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 18/60... -
Page 19: Relay Contact
ComBricks via copper to one of the copper channels of the ProfiHub B2FOR+ or B4FOR+. ProfiHub B4FOR+ Fig. 13 - Example topology for a fiber backbone with ProfiHubs ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 19/60... -
Page 20: Calculating The Delay Time
‘No signal’ alarm. If the ‘Ring’ switch is on, then both fiber ports must be enabled and connected to ring ports of other compatible Hubs. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 20/60... -
Page 21: Spur Segments
Channel should be blinking. According to UL60950-1, if a copper PROFIBUS cable is used outside, it is required to install surge protection that is suitable for PROFIBUS. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 21/60... -
Page 22: Termination
The auto baudrate detect feature will search for the correct baud rate within 10 seconds of receiving the first telegram. This baud rate lock will be lost after 50 seconds of incorrect or no message reception. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 22/60... -
Page 23: Robust Repeating Mode
MinTSDR in the PLC busparameters slightly. Recommended is to increase the MinTSDR with a value according to the Delay Time table, column ‘Robust Mode’, described in the Technical Data chapter. Generally a MinTSDR of 25 is sufficient. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 23/60... -
Page 24: Channel Redundancy
MinTSDR in the PLC busparameters slightly. Recommended is to increase the MinTSDR with a value according to the Delay Time table, column ‘Robust Mode’, described in the Technical Data chapter. Generally a MinTSDR of 25 is sufficient. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 24/60... -
Page 25: Diagnostics Device
You can use a ComBricks to display the most important diagnostics of every channel. The information of this ProfiHub Diagnostics slave is displayed as follows: Fig. 17 - Information window of the Diagnostic slave ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 25/60... - Page 26 Illegals Power input changed Internal Diagnostics Termination of Channel changed External Diagnostics Communication on Channel stopped/started Diagnostics while in Data Exchange Livelist changed (station removed or added) ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 26/60...
-
Page 27: Setting Up The Diagnostics Device
‘Set Slave Address’ command. Most configuration tools support this feature. Fig. 20 - ProfiCaptain changes the address from 126 to 20 ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 27/60... -
Page 28: Gsd File
3.1.3 GSD file Locate and download the appropriate GSD file for the Diagnostics Device on www.procentec.com/downloads . The correct GSD file for the ProfiHub B2FOR+ is: PROC6975.gsd. The correct GSD file for the ProfiHub B4FOR+ is: PROC6976.gsd. The zip file also contains the corresponding .bmp (Bitmap) files. Import the GSD file into your configuration tool and insert the device in the PLC hardware configuration. -
Page 29: Baudrate Status
0x21: Power 1 is active, pending alarm: Power 2 not active 0x32: Power 2 is active, pending alarm: Power 1 and 2 not active (Relay should be reset in this case) ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 29/60... -
Page 30: Termination Status
Fiber optic port 2 signal warning critical level 3 dec Fiber optic port 2 Ok Bit (5..4) Meaning 0 dec Ring mode off (line mode) 1 dec Ring Failure 2 dec Ring Ok ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 30/60... -
Page 31: Livelist Status
Livelist of Channel 1 Livelist of Channel 2 Livelist of Channel 3 Livelist of Channel 4 None Livelist of this ProfiHub Livelist of all channels (entire network) ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 31/60... -
Page 32: Statistics (Short Format, Long Format )
Statistics of Channel 1 Statistics of Channel 2 Statistics of Channel 3 Statistics of Channel 4 None Statistics of this ProfiHub Statistics of all channels (entire network) ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 32/60... - Page 33 Clear INT. DIAG statistics Clear EXT. DIAG statistics Clear DIAG WHILE IN DX statistics Example: To clear all LOST and ILLEGALS statistics, send 0x11 To clear all statistics, send 0xFF ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 33/60...
-
Page 34: Parameterizing The Diagnostic Device
In this byte, bit 0 to 6 correspond with the parameter message. Bit 7 indicates that at least one of the Statistic Change options has been enabled. Bit 7 of byte 18 of a diagnostics byte indicates that the Diagnostics on Fiber optic has been enabled. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 34/60... -
Page 35: Statistics
All Events described in paragraph 3.3.1 can trigger the Extended Diagnostic bit of the Diagnostic Device. By default, the Extended Diagnostic option is disabled. Each item can be enabled individually. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 35/60... -
Page 36: Extended Diagnostics On Statistics Change
3.3.4 Extended Diagnostics on Statistics change The Extended Diagnostic option can also be enabled for each individual available statistic. This works the same way as the Events described in paragraph 3.3.1. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 36/60... -
Page 37: Alarm Relay On Events Change
3.3.2. When such an (enabled) Statistic change occurs, the Relay will be switched immediately without delay. The only Statistic that can delay the closing of the Alarm Relay is the Lost event. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 37/60... -
Page 38: Changing The Diagnostics Duration/Timeout
You can change the duration of the Extended Diagnostics warning in steps of 100 milliseconds. The default value is 10, so 1 second. The maximum value is 255. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 38/60... -
Page 39: Changing The Device Lost Timeout
1 second. Default value is 5, and maximum value is 255. 3.3.9 Changing the data format The data format can be changed if needed. Default is Motorola, high-low-byte format. You can change it to Intel, low-high-byte format. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 39/60... -
Page 40: Technical Data Profihub B2For+ / B4For
0.125 Tbit at 6 Mbps 0.25 Tbit at 12 Mbps Deviation 2 bit times (over the complete message) for received messages is allowed and is corrected to nominal speed when transmitted. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 40/60... - Page 41 Formula to calculate number of cascading units with adjusted Tslot : Number cascading units = (Tslot - maxTsdr) / (2× Data_delay_time_unit) * Data_delay_time_unit: Normal or Robust mode see table ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 41/60...
- Page 42 Reverse polarity protection < 2.5 mm or 14 AWG Wire diameter Alarm contact Voltage Max. 24 VDC Current Max. 0.5 A Wire diameter < 2.5 mm or 14 AWG ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 42/60...
- Page 43 Standards for safety: UL 60950-1, Information Technology Equipment - Safety - Part 1 General Requirements CAN/CSA C22.2 No. 60950-1-07, Information Technology Equipment - Safety - Part 1: General Requirements T.b.d. MTBF ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 43/60...
-
Page 44: Order Codes
PROFIBUS Repeater with a Single mode fiber optic channel with two ports and ring redundancy, and four RS485 channels with cable redundancy and an integrated Diagnostic Slave. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 44/60... -
Page 45: Glossary
- The first three octets of the user parameterization data are now standardized - Optionally these devices may support: - Acyclic communication (MS1, MS2) - If alarms are used, MS1 shall be supported ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 45/60... - Page 46 A cable attached to a bus segment with a T-connection . Spurs are not recommended with PROFIBUS DP. They are prohibited with 12 Mbps and PROFIsafe operations. German term is "Stichleitung". Stub line See Spur line. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 46/60...
- Page 47 The German PROFIBUS Organization based in Karlsruhe. Drop cable See Spur line. Reflection Part of the original signal that is transmitted back along the cable. It corrupts the original signal. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 47/60...
-
Page 48: Revision History
8 Revision History Version 1.0 First release. ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 48/60... -
Page 49: Sales Offices And Distributors
E: foxon@foxon.cz Czech Republic www.foxon.cz DENMARK ProSaiCon T: +45 70 20 52 01 Jernbanegade 23B F: +45 70 20 52 02 DK 4000 Roskilde E: hfj@prosaicon.dk Denmark www.prosaicon.dk ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 49/60... - Page 50 Netanya, 42170 www.inst-ic.co.il Israel ITALY PROCENTEC Italy T: +39 030 200 8610 Via Branze n. 43/45 F: +39 030 238 0059 25123 Brescia E: www.procentec.it Italy W: www.procentec.it ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 50/60...
- Page 51 POLAND INTEX Sp. z o.o. T: +48 32 230 75 16 ul. Portowa 4 F: +48 32 230 75 17 44-102 Gliwice E: intex@intex.com.pl Poland www.intex.com.pl ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 51/60...
- Page 52 Turkey UNITED ARAB EMIRATES Synergy Controls T: +971 4 3262692 907, IT Plaza Silicon Oasis : F: +971 4 3262693 DubaiI E: sales@synergycontrols.ae United Arab Emirates ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 52/60...
- Page 53 Vietnam For the up to date list of the Sales Offices and Distributors see www.procentec.com/company/distributors/. If your country or region is not listed, please contact us. We are still searching for distributors who can cover complete areas or countries.
-
Page 54: Certificates
10 Certificates ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 54/60... - Page 55 ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 55/60...
- Page 56 ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 56/60...
-
Page 57: Notes
____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 57/60... - Page 58 ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ____________________________________________________________________________________________________________________ ProfiHub B2FOR+ / B4FOR+ User Manual | August 2019 | © PROCENTEC 58/60...
-
Page 59: About Procentec
ComBricks solution has seen PPROCENTEC become the primary manufacturer of network components with the integrated capability for remote monitoring and remote asset-management. Our training facility, the PROCENTEC Academy, has certified over 4000 engineers to implement and maintain their PROFIBUS and PROFINET networks to the highest standards available. - Page 60 PROCENTEC BV Klopperman 16 2292 JD Wateringen The Netherlands T: +31 (0)174 671 800 F: +31 (0)174 671 801 E: support@procentec.com W: www.procentec.com...
