Unpack and inspect

Remove all the packing materials and protective covers and check the components of the kit.
If any component is damaged, notify your supplier and the carrier in writing within three days; state the Item Number
of the kit together with your order number and the supplier's invoice number. Retain the packing materials for
inspection. Do not use the kit if it is damaged.
Check that your kit contains the components listed in
components are packed in three separate bags, labelled bag 1, 2 and 3; the contents of the bags are shown in

If any component is missing, notify your supplier in writing within three days.

If the kit is not to be used immediately, replace the protective covers and repack the components of the kit in the
packing materials. Store the kit in cool, dry conditions until it is required for use.
Bag label Qty
- 1
1
2
1
Bag 1 1
1
1
1
1
1
Bag 2 1
1
1
1
1
1
1
1
1
Bag 3 3
1
1
1
3
1
1
*
If required.
© Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Table
Table 1 - Checklist of cartridge kit components
Description
Cartridge
Gas ballast check-valve
Spring (valve and gas ballast check-valve)
Printed gasket (cartridge)
Dump valve
Oil pressure valve
O-ring: 57.6 x 2.4, viton (cartridge/adaptor)
Coupling element
Inlet-valve 'U' seal
O-ring: 49.5 x 3.0, nitrile (inlet-valve)
O-ring: 7.6 x 2.4, viton (inlet-valve)
O-ring: 32.5 x 3.0, nitrile (inlet-valve)
Spring (inlet-valve)
Printed gasket (top-plate)
O-ring: 42.5 x 3.0, nitrile (inlet connection)
O-ring: 14.6 x 2.4, nitrile (gas ballast control)
O-ring: 21.5 x 3.0, nitrile (gas ballast control)
O-ring: 9.6 x 2.4, viton (mode selector)
Spring (gas ballast control)
O-rings: 21.5 x 3.0, nitrile
*
(gas ballast insert and mode selector)
Shoulder washer
Exhaust diaphragm
Printed gasket (oil-box)
O-rings: 28.2 x 3.53, nitrile
(oil filler-plugs and exhaust-flange)
O-ring: 69.5 x 3.0, nitrile (sight-glass)
O-ring: 15.6 x 2.4, nitrile (oil drain-plug)
1. Note that, except for the cartridge, the kit
*
A653-01-840 Issue F
Table
Figure 1-3
Check ( )
reference
A
210
211
215
217
209
127
411
202-5
202-6
202-7
202-8
213
216
005
203-3
203-4
204-3
212
220
222
301-3
314
319
321
323
Page 3
1.
