Summary of Contents for Edision picco T265
- Page 1 T265 Digital Terrestrial Receiver DVB-T2 H.265/HEVC User’s Guide Support...
- Page 2 The CE certificate of the product is available on our webpage, by visiting this link: https://www.edision.gr/en/support Version of 20 August 2019...
-
Page 3: Table Of Contents
CONTENTS ►Safety ........................ 4-5 ►Remote control ....................6 ►Description ......................7 ►Features ....................... 8 ►Information bar (InfoBar) ..................9 ►EDIVISION – Your electronic program guide ..........10-11 ►Installation ......................12 Terrestrial Scan ........................12 ►Channel ......................13 Organizing Services ......................13 Organizing Favourites ......................15 ►System .......................17 Language ..........................17 Software Update ........................18 A/V Control ..........................19... -
Page 4: Safety
►Important safety instructions 1) Please read these instructions carefully. 2) Keep these instructions in a safe place for future reference. 3) Pay extra attention to «warning» points. 4) Follow all instructions. 5) Do not use the device near water. 6) Clean with a dry cloth only. 7) Do not use near heat sources, such as radiators, heat accumulators, ovens or other devices (including amplifiers) generating heat. - Page 5 This symbol indicates that there is risk of electric shock. This symbol indicates that the operating instructions contain important operating and maintenance information. This symbol indicates that the product has a double insulation between voltage and user accessible parts. Only use parts provided by the manufacturer during repair. This symbol on the product or in the operating instructions indicates that the electrical or electronic device must be disposed of separately from household waste at the end of the service life.
-
Page 6: Remote Control
2. Increasing/decreasing volume [VOL+ , VOL-] NUMERIC KEY (0-9) 3. Switching between TV/AV mode [TV/AV] Control the numerical operation The other 39 keys are for the control of the EDISION and change the Channel/Service number directly set-top-box. • Press [SET] key in the up right hand side TV keypad panel area con- tinuously for 5 Sec. -
Page 7: Description
►Description Front Panel picco T265 / USB: Connection for USB storage devices Display LED, displays current information Infrared sensor for the reception of remote control commands CH- / CH+ buttons: for moving in the program lists POWER button: Activates/Deactivates the device... -
Page 8: Features
►Features Support • Type: Digital Terrestrial Receiver for DVB-T2 H.265/HEVC with Dolby Support & WiFi • Full HD H.265/HEVC decoding support • Resolution: 480p, 576p, 720p/50Hz, 720p/60Hz, 1080i/50Hz, 1080i/60Hz, 1080p/50Hz, 1080p/60Hz TV Standard • 1 x HDMI output for High definition video/audio •... -
Page 9: Information Bar (Infobar)
►Information bar (InfoBar) When in the TV/Radio mode, the ‘INFO’ button displays an information bar (InfoBar) at the lower edge of the screen. This bar is faded-in up to 10 seconds. How to change the duration of fading of the information bar: Press the ‘MENU’... -
Page 10: Edivision - Your Electronic Program Guide
►EDIVISION - Your electronic program guide Standard: EDIVISION is an electronic program guide with its own OSD menu. EDIVISION presents the information provided by the service provider in detailed views. In addition, up to 8 time-controlled recordings (Timer) can be programmed from here. Note that not all channels/program providers provide program-related information. - Page 11 EDIVISION window in ‘Timetable’ mode To navigate in the channel list and by using the PREV/NEXT buttons to navigate with daily overview. Use the up/down arrow buttons to navigate between the weekdays in the respective list. If the cursor is located on the right-hand column side of a program title, even more detailed information about this...
-
Page 12: Installation
►Menu program ► Installation ► Channel ► System ► Media / Internet ►Ιnstallation ► Terrestrial Scan Terrestrial Scan Press [OK] key to enter the selected item. You can select the Bandwidth by region (country). You can set the Tuner Power ON/OFF. Press [Red] key can directly into blind scan mode to scan the current... -
Page 13: Channel
► Channel ► Organizing Services ► Organizing Favourites Organizing Services Your channel list(s) for TV or Radio channels can be customized in this menu. Notes: Make sure the receiver is in the correct mode. If wanting to edit radio channel lists, the receiver must be in radio mode. - Page 14 Tip: It is possible to move multiple channels simultaneously by selecting the respective channels first in the channel list (left menu page) with the OK button and then carrying out steps 2-5 as explained above. How to lock a channel: Move the cursor (yellow bar) in the channel list to the channel to be locked.
-
Page 15: Organizing Favourites
Exit the ‘Edit channel’ menu by pressing the EXIT button. If changes were made, a dialogue window appears prompting you to confirm these changes. The changed settings are saved by selecting ‘Yes’. Note: Channel is only deleted, moved and/or locked upon confirmation with ‘Yes’. NO changes are saved when selecting ‘No’. - Page 16 Press the OK button. The channel is inserted at the end of the favourite list. The channel is marked with a symbol on the left side of the menu. Tip: It is possible to add multiple channels simultaneously to the favourite list by selecting the respective channels first in the channel list (left menu page) with the OK button and then carrying out steps 2-3 as explained above.
-
Page 17: System
►System ► Language ► Software Update ► A/V Control ► Time Setting ► Timer ► Parental Control ► Miscellaneous Settings ► Default setting ► Information Language Functions and settings in the menu: Menu language: Select the language in which the Menu is displayed. -
Page 18: Software Update
Save the file downloaded from your PC onto the USB data storage and plug this data storage into the USB port of ‘picco T265’. Note: In these circumstances, the upload speed via USB depends on the Organisation of the data on the USB memory. -
Page 19: A/V Control
A/V Control Functions and settings in the menu: Display Mode: Select here between the options Auto, By Native TV, 720p_50, 720p_60, 1080i_50 or 1080i_60. Aspect Mode: Determine here the aspect ratio with which the image will be displayed. (16:9, 4:3PS, 4:3LB, AUTO) Video Output: Select the colour mode for image... -
Page 20: Timer
Timer Up to 8 time-based events can be programmed in this menu. In addition to programming recordings of Radio or TV channels, it is also possible to display events, such as a nice birthday or anniversary greeting at a certain time or specify to which channel to be woken up. -
Page 21: Parental Control
Parental Control You can set a password for “Installation” menu configuration. You can also set a password for channel locking. (For lock channel settings, please refer to LOCK section) Here in ‘Parental Control’ you can find out how to set and/or change the password. In “Parental Lock”... -
Page 22: Default Setting
Default setting Use the up/down arrow buttons to select one of the following menu items and press the OK button. Functions and settings in the menu: Factory setting: Use of this function deletes ALL user programmed values and reinstalls factory settings. -
Page 23: Media / Internet
►Media / Internet ► File List ► Storage Information ► PVR setting ► USB Speed Test ► Remove USB Device Safely ► Ethernet Settings ► YouTube ► Weather Forecast ► Rss Reader File List The arrow buttons enable the selection between «Image», «Video», «Software», «All»... -
Page 24: Pvr Setting
button (HDD formatting). Specify in the ‘HDD Formatting’ menu the file system with which the USB memory should be formatted (FAT or NTFS). Please note that this will delete all existing files on this USB memory. PVR setting Note: This menu item is available provided that you have connected a USB memory device with a recording speed... -
Page 25: Remove Usb Device Safely
Remove USB Device Safely Safely remove the USB device Ethernet Settings Menu functions and settings: Tip: The items IP Address, Subnet Mask, Gateway, DNS Preferred and DNS Alternate are available only if item ‘DHCP’ is set to ‘OFF’. DHCP: If you install a DHCP server on your network, you can automatically provide an IP address to your receiver. - Page 26 - Restarting... Auto update If you select this menu item, the receiver will try to connect with the factory-configured server of EDISION. Provided that the cables are properly setup and the values that correspond to your network in the ‘Network Settings’...
-
Page 27: Youtube
ΥουΤube Access your favorite YouTube videos Weather forecast Weather information through your favorite EDISION receiver Rss Reader Keep up-to-date, from your favorite websites, through Rss Reader Version of 20 December 2018... - Page 28 . e d i s i o n . g r EDISION HELLAS LTD • FARMAKEIKA - 57001 N. RISIO • THESSALONIKI - GREECE...
Need help?
Do you have a question about the picco T265 and is the answer not in the manual?
Questions and answers
Come cambiare la lingua( per sbaglio) dopo la prima accensione
To change the language on the Edision Picco T265 after the initial setup:
1. Go to the Control menu.
2. Navigate to Miscellaneous Settings.
3. Select Default setting.
4. Open the Information Language menu.
5. Choose Menu language and select the desired language.
6. Exit the menu by pressing the EXIT button.
This answer is automatically generated
