Summary of Contents for Edision Progressiv Hybrid lite
- Page 1 progressiv hybrid lite LED FullHD DVB-C/T2 Receiver User’s Guide hybrid lite h y b r i d l i t e...
-
Page 2: Table Of Contents
CONTENTS ►Safety ........................ 4-5 ►Remote control ....................6 ►Description ......................7 ►Features ....................... 8 ►Information bar (InfoBar) ..................9 ►EDIVISION – Your electronic program guide ..........10-11 ►Channel ......................12 Edit channel ..........................12 Edit favourites ........................14 ►Installation ......................16 Terrestrial Installation ......................16 Cable Installation ........................18 Network ID Scan ........................18 ►Menu system settings ..................18 Language ..........................18... - Page 3 ►Media ........................25 File List ..........................25 Memory Information ......................25 Check-Speed USB ........................ 26 USB Safely Remove ......................26 ►Internet .......................27 Ethernet Settings ........................27 YouTube ..........................28 Web TV ..........................28 Pss Reader ...........................28 Weather Forecast ........................29 Google Maps ........................29 Version of 14 June 2016...
-
Page 4: Safety
►Important safety instructions 1) Please read these instructions carefully. 2) Keep these instructions in a safe place for future reference. 3) Pay extra attention to «warning» points. 4) Follow all instructions. 5) Do not use the device near water. 6) Clean with a dry cloth only. 7) Do not use near heat sources, such as radiators, heat accumulators, ovens or other devices (including amplifiers) generating heat. - Page 5 This symbol indicates that there is risk of electric shock. This symbol indicates that the operating instructions contain important operating and maintenance information. This symbol indicates that the product has a double insulation between voltage and user accessible parts. Only use parts provided by the manufacturer during repair. This symbol on the product or in the operating instructions indicates that the electrical or electronic device must be disposed of separately from household waste at the end of the service life.
-
Page 6: Remote Control
►Remote control On / Off button Mute On/Off Selection of TV/Radio program. Input of numbers or letters in the menus Toggles between TV and Radio mode Returns to the previous program ZOOM Displays the main menu Displays the information bar Use the arrow buttons to navigate through the menu. -
Page 7: Description
►Description Front Panel hybrid lite Infrared sensor for the reception of remote control commands Display LED, displays current information Card reader Back Panel DC 5V/1,0 A ANT IN S/PDIF HDMI SCART ANT IN: Input for connecting the signal from the antenna S/PDIF: Audio interface for amplifier/audio console HDMI: Connection to an HDTV quality TV SCART: For connecting to a TV set,... -
Page 8: Features
Language Selection ►Features • Type: DVB-T2 / DVB-C, Hybrid Full HD receiver. • Digital Terrestrial, Mpeg-4. • Resolution 480p, 576p, 720p/50Hz, 720p/60Hz, 1080i/50Hz, 1080i/60Hz, 1080p/50Hz, 1080p/60Hz TV- Standard • 1 x Card Reader • 1 x HDMI Output for Full HD video/audio •... -
Page 9: Information Bar (Infobar)
►Information bar (InfoBar) When in the TV/Radio mode, the ‘INFO’ button displays an information bar (InfoBar) at the lower edge of the screen. This bar is faded-in up to 10 seconds. How to change the duration of fading of the information bar: Press the ‘MENU’... -
Page 10: Edivision - Your Electronic Program Guide
►EDIVISION - Your electronic program guide Standard: EDIVISION is an electronic program guide with its own OSD menu. EDIVISION presents the information provided by the service provider in detailed views. In addition, up to 8 time-controlled recordings (Timer) can be programmed from here. Note that not all channels/program providers provide program-related information. - Page 11 EDIVISION window in ‘Timetable’ mode To navigate in the channel list and by using the PREV/NEXT buttons to navigate with daily overview. Use the up/down arrow buttons to navigate between the weekdays in the respective list. If the cursor is located on the right-hand column side of a program title, even more detailed information about this...
-
Page 12: Channel
►Menu program ► Channel ►Menu Installation ► Settings ► System ► Media ► Internet ► Channel ► Edit channel ► Edit favourites Edit channel Your channel list(s) for TV or Radio channels can be customized in this menu. Notes: Make sure the receiver is in the correct mode. - Page 13 Select TP: All channels of a transponder can be selected here. The ‘FIND’ button allows quick search for channel (names). A search window appears after pressing this button. Entry into the search field is done via a letter or numeric field actuated with the arrow buttons and by pressing the OK button.
- Page 14 character in the letter field. A space is added by navigating with the arrow buttons to the character. Confirm your entry by navigating with the arrow buttons to the ‘OK’ area. The new name is now added to the channel list. The input window can be exited at all times by using the EXIT button and thereby cancelling the process.
- Page 15 When in the left column, the ‘FIND’ button enables quick search of channel names. The search window appears after pressing this button. Entry into the search field is done via a letter or numeric field actuated with the arrow buttons and by pressing the OK button. Provided that channels with appropriate initial characters are found in the list, these will be displayed on the left-hand side.
-
Page 16: Installation
‘<-’ character in the letter field. A space is added by navigating with the arrow buttons to the character ‘--‘. Confirm your entry by navigating with the arrow buttons to the ‘OK’ area. The input window can be exited at all times by using the EXIT button and thereby cancelling the process. Exit the ‘Edit favourites’... - Page 17 Cable Installation Press [OK] key to enter the selected item. You can select the Scan Mode, Manual Scan or Blind Scan. You can input the Frequency by use the numeric button of the RCU. You can input the Second Frequency by use the numeric button of the RCU, if you set the Scan Mode to Blind Scan.
-
Page 18: Menu System Settings
►Menu system settings ► Languages ► A/V Control ► Time setting ► Timer ► Parental Control ► Factory setting ► Information Languages Functions and settings in the menu: Menu language: Select the language in which the Menu is displayed. First audio: Set the audio language here for the first channel. -
Page 19: A/V Control
in this item, accessing the menu is only possible via PIN code. Channel bar, EDIVISION and favourite lists are exempt. Channel lock: Specify here whether or not channels can be locked in general. New password: Specify a new password here. Confirm password: Repeat the new password. -
Page 20: Timer
Date: This item can only be reached when the ‘Off’ option was set for the ‘GMT User’ item. Enter the date via the number buttons. Time: This item can only be reached when the ‘Off’ option was set for the ‘GMT User’ item. Enter the time via the number buttons. -
Page 21: Parental Control
Parental Control You can set a password for “Installation” menu configuration. You can also set a password for channel locking. (For lock channel settings, please refer to LOCK section) Here in ‘Parental Control’ you can find out how to set and/or change the password. In “Parental Lock”... -
Page 22: Information
Http Upgrade Auto Upgrade When selecting this menu item, the receiver tries to connect with the factory-set server by EDISION. A correct cable configuration and providing the proper values in ‘Network Settings’ menu item according to your network, the receiver connects and retrieves the file list from the server. - Page 23 ‘USB/HDD Update’ is that the appropriate software file is located on the USB data storage. This file with the ‘.abs’ file extension can be downloaded from the Edision website via a PC with Internet connection. http://www.edision.gr “Progressiv HD C nano plus”...
- Page 24 Backup to USB/HDD Functions and settings in the menu: Backup of the file: Determine the file name for the backup file here. Press the OK button to display a letter and number field and specify with the arrow buttons and OK button the name for the backup file. Delete the last character by navigating in the letter field with the arrow buttons to the area ‘<-’...
-
Page 25: Version Of 14 June
Functions and settings in the menu: Port: Show information about an existing card into port. Information Smart Card: Here you can set if you want to display information about the inserted card or not. Exit the menu «Smart Card» or «Info Smart Card» by pressing the EXIT button. ►Media ►... -
Page 26: Check-Speed Usb
Check-Speed USB In this menu item you can control the speed of the connected USB memory device. The window displays the estimated transfer / write speed and if this speed is suitable for storing high definition channel content. Furthermore you see how many channels can be recorded simultaneously. -
Page 27: Internet
►Internet ► Ethernet Settings ► YouTube ► Web TV ► Rss Reader ► Weather Forecast ► Google Maps Ethernet Settings Note: The IP Address, Subnet Mask, Gateway, DNS Preferred and DNS Alternate items are only accessible if the ‘Off’ value is set at the ‘DHCP’... -
Page 28: Youtube
ΥουΤube Access your favorite YouTube videos Web TV Features Web TV Rss Reader This menu item offers access to brief information from the Internet. The list of the information providers (RSS channel list) can be found in the left column and in the right column (RSS news list), news reports and information provided, if available via Internet. -
Page 29: Weather Forecast
Notes: Use the numeric key 1 to input the following special characters: . , * ? ! @ . Enter the characters _ - / : via the ZOOM or 0 button. Use the yellow button to delete a character, the green button to switch between lower and upper case spelling. - Page 30 w w w . e d i s i o n . g r DC 5V/1,0 A ANT IN S/PDIF HDMI SCART A N T I N S / P D I F H D M I S C A R T D C 5 V / 1 , 0 A...
