Edision Progressiv HD c+ Manual

Congratulations on purchasing an EDISON progressive HD c+
Please note that this information is valid at the time of publication.
Current information and detailed user manuals can be found on the Internet at: www.edision.gr
1
Unpacking
115mm
Receiver progressive HD c+
Notes: The front is factory fitted with a protective foil
which can be removed easily and with caution. (Protective foil only for devices with display)
The scope of delivery may also include parts not listed here
Front Panel
1
/USB: Connection for USB1 storage devices
2 Infrared sensor for the reception of remote
control commands
Back Panel
3 LNB IN: Connection for the coaxial cable
to the signal from the satellite system
4 HDMI: Connection to an HDTV quality TV
5 IR IN: Infrared connection port
6 AV OUT: For broadcasting video and sound signals
7 Connection for an adapter (DC 12V/2A)
Subpage
8 Card reader
2
Connecting and switching on
Note: For interference-free satellite TV reception,
a specialist technician must calibrate your satellite
TV system with a digital TV level meter
• Connect the receiver using HDMI cable via the
HDMI output port to your TV's HDMI input port
• Now connect the receiver to the satellite
antenna cable via the LNB IN input.
• Insert the batteries into the remote control.
Notes on the remote control can be found on
the back of these instructions.
• Connect the receiver to the power supply.
• The receiver starts with the BOOT process and
is operational within a short time
progressiv HD c+
F u l l H D S AT R e c e i v e r
Remote control with 2 AAA batteries
2
LNB IN 13/18V
400mA Max
3
8
LNB IN: Connecting
the cable to the satellite
signal
LNB IN 13/18V
HDMI
400mA Max
HDMI: Output receiver
HDMI
kabel
Documentation
HDMI
IR
4 5
AV DC-12V
IR
Power socket
HDMI cable
Service note
Please contact
your EDISION
specialist dealer
for any further
support
and service.
USB
1
+
progressiv HD c
AV DC-12V
6 7
TV set connection panel
Use an HDMI input!
HDMI in
2
1
m
HD i
kabel
