Processor Port Pin Assignments
This section describes the pin assignments for the
management access ports on the system processor.
Table 6 shows the modem port pin assignments.
Table 7 shows the terminal port pin assignments.
Table 8 shows the pin assignments for the
out-of-band 10BASE-T Ethernet port.
Table 6 Modem Port Pin Assignments
Pin No. Signal
Description
1
DCD
Data carrier detect
2
RXDA
Received data
3
TXDA
Transmitted data
4
DTR
Data terminal ready
5
Signal ground
6
Not used
7
RTS
Request to send
8
CTS
Clear to send
9
Not used
Cabling the System Processor Ports
Table 7 Terminal Port Pin Assignments
Pin No.
Signal
Description
1
Not used
2
RXDB
Received data
3
TXDB
Transmitted data
4
Not used
5
Signal ground
6
Not used
7
Not used
8
Not used
9
Not used
Table 8 10BASE-T Port Pin Assignments
Pin No.
Signal
Description
1
TD +
Transmit Data +
2
TD –
Transmit Data –
3
RD +
Receive Data +
4
Not used
5
Not used
6
RD –
Receive Data –
7
Not used
8
Not used
33
