PB TEEN Locker Under Bed Storage Assembly Manual

Locker Under Bed Storage

Pre-Assembly:

Please read all instructions before beginning assembly.

Two-adult assembly is recommended.

Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or

hardware.

If using power tools to aid in assembly please use with caution. Power tools can damage hardware.

Note: Do not full tighten all bolts until all parts are in place. Failure to follow these instructions may cause the bolts

to misalign during assembly.

Open Wrench

A – Storage – 1pc

a – Caster without Brake – 2pcs

Note: All parts and hardware are delivered in one carton.

1. The handle is pre-assembled on the interior of the drawer. Use a Phillips head screwdriver to unscrew and

remove the handle and washers from drawer, then re-attach the washer and handle to the drawer as shown.

See Figure 1.

b – Caster with Brake – 2pcs

- 1 -

www.pbteen.com

Table of Contents

Do you have a question about the Locker Under Bed Storage and is the answer not in the manual?

Page 1 Locker Under Bed Storage Pre-Assembly: Please read all instructions before beginning assembly. Two-adult assembly is recommended. Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or hardware. If using power tools to aid in assembly please use with caution. Power tools can damage hardware.
Page 2 Figure 1 2. Carefully lay down the storage (A) on a carpet or scratch-free surface. Attach the caster (a & b) to the corner of storage bottom as shown, tighten the caster with open wrench. See Figure 2 open wrench Figure 2 3.
