π
H-2323
®
Swingline
toucH
™
Heavy duty
deSktop manual Stapler
COMpatiBLe StapLeS
5/8"
S-14967
1.
Push load button to release magazine. (See Figure 1)
2. Pull the magazine all the way out until it stops.
(See Figure 2)
3. Load 5/8" Heavy Duty Staples (S-14967).
(See Figure 3)
4. Push magazine closed until you hear an audible
click.
PAGE 1 OF 2
1-800-295-5510
uline.com
ligHt
OperatiOn
Figure 1
Figure 2
Figure 3
0814 IH-2323
Advertisement
Table of Contents
Related Manuals for U-Line Swingline Light Touch H-2323
Summary of Contents for U-Line Swingline Light Touch H-2323
- Page 1 π H-2323 1-800-295-5510 uline.com ® Swingline ligHt toucH ™ Heavy duty deSktop manual Stapler COMpatiBLe StapLeS 5/8" S-14967 OperatiOn Push load button to release magazine. (See Figure 1) Figure 1 2. Pull the magazine all the way out until it stops. Figure 2 (See Figure 2) 3.
- Page 2 OperatiOn COntinued 5. To adjust paper depth, move depth guides forward Figure 4 to unlock. Adjust paper depth guide to desired position and move guides backward to lock depth guide in place. (See Figure 4) Depth Guide 6. Insert paper into paper depth guide as shown for Figure 5 angled stapling.
