Eaton ELC-GPXFERMOD Instruction Sheet

ELC-GPXFERMOD
GP Transfer Module
Always read this manual before using the ELC-GPXFERMOD.
ELC-GPXFERMOD doesn't support plug and play function. Please turn off power before plugging in
ELC-GP02 or ELC-GP04.
The voltage for ELC-GPXFERMOD is supplied from GP extension port. Please confirm
ELC-GPXFERMOD plugged direction when connecting to GP extension port to avoid serious damage.
Item
Data Reserved Life
Times for Writing In
Operation Temperature
Weight / Dimension
The function of transfer module that ELC-GP Series provides to copy user program, system function and
passwords is different from the copy program. It is used to copy the whole HMI environment settings and
application programs to another HMI rapidly. It can save much time and manpower. The operation is in the
following.
Definition: Transfer module (ELC-GPXFERMOD) = XMOD, GP Series = GP
Step
1
Turn the switch on the XMOD to GP XMOD
2 Insert the XMOD into the expansion port of GP
3 Input the power to GP
4 It will display "remove XMOD" on the screen and
power on again

ELECTRICAL SPECIFICATION

MEMORY TRANSFER MODULE FUNCTIONS

GP XMOD
Instruction Sheet

WARNING

ELC-GPXFERMOD
20 years
100,000 Cycles
0ºC~55ºC
3g / 50.85×19.8×10 mm
Turn the switch on the XMOD to XMOD GP
Insert the XMOD into the expansion port of GP
Input the power to GP
It will display "remove XMOD" on the screen and
power on again
IL05003013E.pdf
XMOD GP
