- Page 1 LinkPlus Interface Guide Avaya DEFINITY Communications System Link Wireless Telephone System NetLink Wireless Telephone Part Number: 72-0171-01 Issue B...
- Page 2 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System NOTICE SpectraLink Corporation has prepared this document for use by SpectraLink personnel and clients. The drawings and specifications contained herein are the property of SpectraLink and shall be neither reproduced in whole or in part without the prior written approval of SpectraLink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.
-
Page 3: Contacting Spectralink
SpectraLink is the market leader in multi-cellular wireless telephone systems for the workplace. We manufacture a range of products to suit any size installation. All SpectraLink products use our LinkPlus digital integration technology to integrate with various digital switch platforms. Using LinkPlus technology, Wireless Telephones emulate digital telephone sets to deliver advanced capabilities such as multiple line appearances and LCD display features. -
Page 4: Plan Programming
SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System 2. Plan the Interface The system administrator programs the telephone system for use with the Wireless Telephone System using the normal administration terminal or procedures. Programming can be done after the Wireless Telephones are registered. - Page 5 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System - where is this extension forwarded on busy/no answer? Coverage - to which group does this extension or group of extensions belong? Call Pickup Group - to which Class of Restriction group should the Wireless Telephones...
- Page 6 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System The SpectraLink Wireless Telephone Display The Wireless Telephone has a two-line, 16-character alphanumeric display. Certain characters may be used by the system that are not implemented in the Wireless Telephone. Flashing characters are not implemented on the Wireless Telephone, nor is rolling or scrolling of text.
- Page 7 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System Feature Programming Requirements When planning the interface, the following information must be taken into account: Line Sequences The Wireless Telephone uses two types of key sequences to access PBX features and multiple lines.
- Page 8 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System Delay (same as the Link 3000 MCU). See the NetLink Wireless Telephone: Setup and Administration document for the NetLink for further details. Also refer to the NetLink Telephony Gateway: Setup and Maintenance document for details on configuring the telephone switch type.
- Page 9 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System 3. Interface Implementation This section describes the recommended programming to use the SpectraLink Wireless Telephone System with a DEFINITY Communications System. The procedures assume: • The DEFINITY system is installed and operational in an approved configuration. See the Telephone Switch Interface Matrix document for tested configurations.
- Page 10 From the block or patch panel the stations are wired to a modular jack. The jack can connect to a short patch cord that connects to the MCU. The following table shows the Avaya side of the block or patch panel wiring. Pair...
- Page 11 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System The following table shows the patch cord pinout for the Avaya side of the modular 8-pin (RJ45) connector. Function Receive Receive Transmit Transmit Each digital pair is polarity insensitive. If you reverse polarity the system will still work.
- Page 12 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System Key-mapping the Wireless Telephone to Emulate 8410D Functionality Programmable buttons on Page 2 of the station form can be assigned as determined in the pre-installation procedures. The following diagram shows how the 8410D buttons map to the Wireless Telephone.
-
Page 13: Program Definity
SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System Program DEFINITY Each Wireless Telephone must be administered on the DEFINITY so the switch will recognize the Wireless Telephone and allow access to system facilities and features. The DEFINITY technician or local system programmer should perform the necessary programming. - Page 14 SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System messages, they can be customized using DEFINITY’s Language Translations feature. Assign Buttons The technician can Assign Call Appearances, Line (trunk) Appearances, and features to buttons to fit user needs. If the Wireless Telephone will be used in conjunction with a wired station, administer the Wireless Telephone as a Bridged Appearance of the wired station.
-
Page 15: Extension Assignments Worksheet
SpectraLink Corporation LinkPlus Interface Guide Avaya DEFINITY Communications System 4. Extension Assignments Worksheet Shelf: _______ Interface Module: _______ Phone # Ext. # Name Interface Comment Wireless Module Telephone Circuit # Serial # Phone 1 Phone 2 Phone 3 Phone 4...
