CR501/CR5001&CR601/CR6001

2. Basic Operations

The icons in black at the bottom of
the screen indicate the available
actions, which can be done by
pressing the corresponding buttons
on the tool.
Read DTC
Press the F1/DTC button to retrieve
Ÿ
the DTC.
Press the F4/ button to get more
Ÿ
?
details about the DTC.
If more than one DTC was retrieved,
Ÿ
press / to view different DTCs.
In the case of long code definitions,
Ÿ
use / to view the additional
information.
Erase DTCs
Once DTCs have been retrieved,
press the F2/ER button to erase.
Check I/M Readiness
Press the F3/I/M button to check the
I/M(Inspection & Maintenance)
readiness.
Quick Start Guide
Monitor Status
MIL Status OFF
DTCs in this ECU 108
Readiness Completed 5
Readiness Not Completed 2
Readiness Not Supported 3
Datastream Supported 119
Ignition Spark
Protocol Type CAN
?
DTC
C138F 1/13
GM Pending
The fault code is not found in the database
?
Erase Codes
Clear/Reset Emission-Related Diagnostic
Information. Are you sure?
?
I/M Readiness
Misfire Monitor N/A
Fuel system OK
component monitor INC
Catalyst monitor N/A
1~ 4/10
3. Register & Update
The tool can be updated via USB cable.
Note: Make sure the PC has an Internet connection.
1. Go to http: mycar.x431.com //
to the computer.
2. Decompress and install it on your computer(compatible with
Windows XP, Windows 7, Windows 8 & Windows 10).
3. After installation, connect one end of the USB cable to the
USB port of PC, and the other end to the tool.
4. If a newer version is found, a screen similar to Fig. A will
appear.
Boot Version:
V1.00.000
Serial Number:
972890000029
Register Code:
36FFDB054753
1. USB Connected for Upgrade.
2. Press [EXIT] key to Enter
Normal Mode.
5. Launch the update tool on your PC,
reading the tool. Once it obtains the tool information, it will
directly navigate to the update center.
6. Click [Upgrade] to start updating.
7. Once update is complete, a "Upgrade success" message
box will pop up.
8. The update process is complete, your tool is now ready for
use.
LAUNCH
/ and download the update tool
A
the system starts
