Summary of Contents for AVMATRIX PVS0605
-
Page 2: Table Of Contents
Contents 1.Brief Introduction .............................1 1.1 Overview ..............................1 1.2 Main Features ............................1 2. Connections ..............................2 2.1 Interfaces ..............................2 2.2 Specification .............................3 3. Control Panel ..............................5 3.1 Description ...............................5 3.2 Keyboard Button ............................6 4. Operation Instrubtion ............................9 4.1 Multiview Output Layout .........................9 4.2 T-Bar Calibration .......................... -
Page 3: Brief Introduction
1.Brief Introduction 1.1 Overview The video switcher is an all-in-one 6-channel video switcher that allows video switching, audio mixing, and video recording. 1.2 Main Features 6 channel inputs: 4xSDI and 2xDVI-I/HDMI/VGA/USB player inputs 2xSDI & 1xHDMI PGM outputs, 1xSDI AUX output, 1xSDI & 1xHDMI multiview outputs Input format auto-detected and PGM/AUX output format selectable Remote PTZ camera control: Visca &... -
Page 4: Connections
2. Connections 2.1 Interfaces Power Switch 1×SDI AUX Output 12V DC Power Input 2×SDI PGM Outputs 12V DC Power Output 4×SDI Inputs RS422 for Camera Remote Control 2×DVI-I(VGA) Input RJ45 For Sync Time & Firmware Upgrade 2×HDMI Input XLR Balanced Audio(L/R) Input 1×SD Slot for Record RCA Stereo Audio(L/R) Input/ Output 2×USB INPUT for Video/ Image Media Player... -
Page 5: Specification
2.2 Specification Video Inputs SDI×4, HDMI/DVI-I/VGA/USB×2 Bit Rate 270Mbps~3Gbps Return Loss >15dB, 5MHz~3GHz Signal Amplitude 800mV±10% (SDI/HDMI/DVI/VGA) Impedance 75Ω (SDI/VGA), 100Ω (HDMI/DVI) 1080p 60/59.94/50/30/29.97/25/24/23.98 1080psF 30/29.97/25/24/23.98 SDI Input Format 1080i 60/59.94/50 720p 60/59.94/50/30/29.97/25/24/23.98 625i 50 PAL, 525i 59.94 NTSC 4K 60/50/30, 2K 60/50/30 1080p 60/59.94/50/30/29.97/25/24/23.98/23.976 HDMI Input Format 1080i 50/59.94/60... - Page 6 PGM Outputs 2×HD/3G-SDI; 1×HDMI Type A AUX Output 1×HD/3G-SDI 1080p 50/60/30/25/24 PGM Output Format 1080i 50/60 Multiview Output 1×HD/3G-SDI; 1×HDMI Type A Outputs Multiview Output Format 1080p 60 Return Loss >15dB 5MHz~3GHz Signal Amplitude 800mV±10% (SDI/HDMI/DVI-I/VGA) Impedance SDI: 75Ω; HDMI: 100Ω DC Offset 0V±0.5V 1×TRS(L/R), 50Ω...
-
Page 7: Control Panel
3. Control Panel 3.1 Description Camera Control Audio Mixer Menu Control and Display T-bar Manual Transition Auto, Cut, FTB Transition Effects, MIX, WIPE, DP Luma Key, Chroma Key, PIP, POP, SHIFT USB Media Player Control Program Row Preview Row... -
Page 8: Keyboard Button
3.2 Keyboard Button Camera Control CAM1 and CAM2 buttons are for Camera 1, Camera 2. ZOOM IN and ZOOM OUT to adjust the size of the picture. Press the button, the button LED will be turned on to indicate that the manual mode is enabled. Then the camera can be controlled via the Joystick. - Page 9 PGM PVW Channel Selection PGM row is for selecting the signal source for program. Selected PGM button turns on the red LED. PVW row is for selecting the signal source for preview. Selected PVW button will turns on the Green LED. Color Bar button is for immediate switching the signal source of Program and preview to Color Bar Pattern.
- Page 10 Chroma Key In a chroma key two images are combined using a special technique and a color from one image is removed, revealing another image behind it. Chroma key is commonly used for weather broadcasts, where the meteorologist appears to be standing in front of a large map.
-
Page 11: Operation Instrubtion
4. Operation Instrubtion 4.1 Multiview Output Layout 1) PGM and PVW as Preview and Program displayed as following image. The level meter of PGM audio is shown only in multiview. SDI/HDMI PGM out is without any overlays. 2) The following 6 windows come from the 6 input signals. The signal source of window 5 and 6 can be selected from HDMI, DVI, VGA, USB. -
Page 12: T-Bar Calibration
4.2 T-Bar Calibration The T-Bar of the video switcher may happen to misalignment, when the origin of the coordinates offset the T-Bar calibration is necessary before using. 1) Power off the video switcher, and then press and hold button 1 and 2 of PVW at same time. Hold the buttons until all calibration complete. -
Page 13: Transition Control
4.3.2 Transition Control 1) Transition without Effects CUT performs a simple immediate switch between Preview and Program views. This is no delay seamless switching and the selected transition effect WIPE, MIX or FADE is not used. 2) Transition with Effects AUTO performs an automated switch between Preview &... -
Page 14: Usb Media Player
4.3.5 USB Media Player 1) USB Media Player Setup Plug in the USB flash drive into the USB port in the side panel as below image: Setup the video source of channel 5 or 6 to USB (refer to 4.3.4), then manage the USB media player from the control panel. -
Page 15: Transition Effects
4.4 Transition Effects 4.4.1 MIX Transition Press the MIX button to select a basic A/B Dissolve for the next transition. When button LED turns on it is active. Then use T-Bar or AUTO to operate the transition. And there are 3 different speed rates for choice from the menu. -
Page 16: Pip And Pop
4.5 PIP and POP When the T-Bar located at B-BUS to active the PIP/POP, there will be a small image display on the top left corner of the PVW window as following image: Press button 1-6 from PVW row to switch the video source of PIP/POP. When press PIP/POP button the menu will get into an interface as below image. -
Page 17: Chroma Key
4.6 Chroma Key Turn on the Chroma Key, a color from the key source will be removed, revealing another background image behind it. Chroma Key is usually used for virtual studio, such as weather broadcasts, where the meteorologist appears to be standing in front of a large map. In the studio the presenter is standing in front of a blue or green background. -
Page 18: Ptz Camera Remote Control
5. PTZ Camera Remote Control 5.1 Camera Setting Two PTZ cameras can be control through the RS-422 port of the video switcher. You can pan, tilt, zoom two cameras separately by using a joystick and buttons. Press button CAM1 or CAM2 to select the one you want to control, and the button will be turn on which indicates the camera ins under control. -
Page 19: Menu Settings
6. Menu Settings 6.1 Status Menu The status menu includes Audio settings, and AUX and PGM out settings. All the settings will be saved when you restart the switcher. Main Menu Secondary Menu Option Default IN1/IN2/IN3/IN4/IN5/IN6/XLR_IN/RCA_IN IN1/IN2/IN3/IN4/IN5/IN6/XLR_IN/RCA_IN IN1/IN2/IN3/IN4/IN5/IN6/XLR_IN/RCA_IN Earphone IN1/IN2/IN3/IN4/IN5/IN6/PGM/XLR_IN/RCA_IN STATUS PGM/PVW Audio Mode... -
Page 20: Main Menu
6.2 Main Menu If STATUS menu is unselected, press the MENU button to go to main menu directly. If the menu is selected in the secondary menu, rotate anticlockwise the MENU button to exit the menu and then press the MENU button to go to the main menu. Main Menu Secondary Menu Option Default... -
Page 21: System Settings
Analog or Digital. The time of clock can be set through a PC software through the Ethernet. Connect video switcher to a PC and download a time control software from AVMATRIX official website www.avmatrix.net/download/ Open the software and click Scan button to search and connect the device, then the clock time will be changed to same time to the PC’s time. -
Page 22: Tsl Settings
3) Recording Control Press REC button start recording. Meantime, the button indicator turns on. During recording, press Pause button the recording pause, and press Pause button again recording continue. Press REC button again recording stops and save the video files to SD card. The recording status shown beside the menu, including information of REC mark, recording time, SD card available storage.
