Appendix C - Compatibility
A
PPENDIX
The HiGain system uses HDSL2 transmission technology as recommended by Bellcore TA-TSY-001210. HiGain
HDSL2 complies with GR-63-CORE, TR-TSY-000499, and GR-1089-CORE.
The H2TU-C-231 List 2 is compatible with the following DS1 repeater shelves and associated equipment:
•
HiGain Card Shelf HCS-417 (23" shelf)
•
HCS-418 (19" shelf)
•
HCS-402 (2-slot))
•
AT&T 220 Office Repeater Bay (ORB)
•
AT&T Small Cross-Section Shelf (SXSS)
• Kentrox 220 (The ALM option must be disabled (DIS) to resolve a conflict between the H2TU-C alarm relay
output and the Kentrox external equalizer output. Both use pins 20 and 21.)
®
•
Wescom 342-30
60
C - C
OMPATIBILITY
January 9, 2002
LTPH-UM-1109-01, Issue 1
H2TU-C-231 List 2
