Logon Screen Menus - ADC HiGain H2TU-C-231 User Manual

Provisioning
Most VT100 emulation programs support a print screen option. For Windows-based programs,
such as Procomm or HyperTerminal, do the following:
1 Highlight the screen that you wish to print.
2 Click File, then Print.
3 In the Print dialog box, choose Selection as the Print Range.
4 Click OK to print.
For printing procedures for other programs, contact the appropriate vendor.
Monitor Performance
ID: xxxx--xxxx--xxxx—-xxxx
Circuit ID Number
Press this To access this
key: menu:
M Monitor
P
Performance
E
Event Log
C
Config
I Inventory
O Report
12
Menu bar
Event Log Config
+------------------------------------------+
|
| ADC DSL Systems, Inc.
| HiGain HDSL2
|
| Voice:
| Fax :
+------------------------------------------+
09/01/2001 12:30:01
Date and Time
Figure 3. Logon Screen
Table 4.

Logon Screen Menus

Menu Functions
Monitors loopbacks and alarms, and provides a graphical representation of circuit activity,
including ES, UAS, SES, and line code.
Provides performance and alarm histories for current, 25-hour, 48-hour, or 31-day periods
for either the DS1 or HDSL2 interface.
Identifies the 100 most recent system events and reports the date and time of occurrence.
Provides standard configuration options, ADC options, BER tester (BERT), date and time
setting, and a reset option (factory settings). Also provides a master clear option that clears
all performance, alarm, and event log entries. Selecting the Config menu after a remote logon
displays the BERT Generator menu, which provides access to the BERT Signal Generator
configuration submenu.
Provides product information about the various devices that are in the system and lists circuit
and device identifications.
Provides four types of reports: Full Report, Short Report, System Information Report, and
Event Report.
