This User's Guide describes the characteristics, operation, and use of the
TPS63000EVM evaluation module (EVM). This EVM is designed to help the user easily
evaluate and test the operation and functionality of the TPS63000. This User's Guide
includes setup instructions for the hardware, a schematic diagram, a bill of materials
(BOM), and PCB layout drawings for the evaluation module.
1
2
3
4
1
2
3
4
5
6
7
8
9
1
2
1
Introduction
The Texas Instruments TPS63000 is a high efficient single inductor buck-boost converter in a 10-pin,
3-mm × 3-mm QFN package. Both fixed and adjustable output voltage units are available.
1.1
Background
The TPS63000EVM-148 uses the TPS63000 adjustable version, and is set to 3.3-V output. The EVM
operates with full-rated performance with an input voltage between 3.0 V and 5.5 V.
1.2
Performance Specification
Table 1
provides a summary of the TPS63000EVM-148 performance specifications. All specifications are
given for an ambient temperature of 25°C.
SLVU156 - March 2006
Submit Documentation Feedback
..........................................................................................
..................................................................................
........................................................................................
...................................................................
List of Figures
.....................................................................
............................................................................
............................................................................
................................................................
....................................................................
.....................................................................................
..................................................................................
..............................................................................
...................................................................
List of Tables
............................................................
.............................................................
User's Guide
SLVU156 - March 2006
TPS63000EVM-148
TPS63000EVM-148
1
2
6
8
3
4
4
5
5
6
7
7
8
2
9
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments TPS63000EVM-148
Summary of Contents for Texas Instruments TPS63000EVM-148
-
Page 1: Table Of Contents
3-mm × 3-mm QFN package. Both fixed and adjustable output voltage units are available. Background The TPS63000EVM-148 uses the TPS63000 adjustable version, and is set to 3.3-V output. The EVM operates with full-rated performance with an input voltage between 3.0 V and 5.5 V. -
Page 2: Setup And Results
U1 can be replaced with the fixed version for evaluation. R1 would need to be replaced with a 0-Ω resistor; R2 position would be open. Setup and Results This chapter describes how to properly use the TPS63000EVM-148. Input / Output Connector and Header Descriptions 2.1.1 J1 –... -
Page 3: Turn On Into Electronic Load
Resistance in trace and leads adds to output ripple, and ground lead length increases the amplitude of switching spikes. SLVU156 – March 2006 TPS63000EVM-148 Submit Documentation Feedback... -
Page 4: Output Ripple Vin 3.0 V
Setup and Results L1 Pin VOUT 10 mV/div L2 Pin Figure 2. Output Ripple Vin 3.0 V L1 Pin VOUT 10 mV/div L2 Pin Figure 3. Output Ripple Vin 4.0 V TPS63000EVM-148 SLVU156 – March 2006 Submit Documentation Feedback... -
Page 5: Efficiency Over Li-Ion Cell Range
125°C. Load Transients Load transient response is well regulated. Additional output capacitance reduces voltage over- and under-shoot. LOAD I VOUT 100 mV/div Figure 5. Load Step 100 mA to 500 mA SLVU156 – March 2006 TPS63000EVM-148 Submit Documentation Feedback... -
Page 6: Board Layout
Board Layout Board Layout This chapter provides the TPS63000EVM-148 board layout and illustrations. Layout Figure 6 through Figure 8 show the board layout for the TPS63000EVM-148 PWB. Figure 6. Assembly Layer TPS63000EVM-148 SLVU156 – March 2006 Submit Documentation Feedback... -
Page 7: Top Layer Routing
Board Layout Figure 7. Top Layer Routing Figure 8. Bottom Layer Routing SLVU156 – March 2006 TPS63000EVM-148 Submit Documentation Feedback... -
Page 8: Schematic And Bill Of Materials
Schematic and Bill of Materials Schematic and Bill of Materials This chapter provides the TPS63000EVM-148 schematic and bill of materials. Schematic Figure 9. TPS63000EVM-148 Schematic TPS63000EVM-148 SLVU156 – March 2006 Submit Documentation Feedback... -
Page 9: Tps63000Evm-148 Bill Of Materials
