Electric Connections - Key Automation CT102 Instructions And Warnings For Installation And Use

EN
4 - PRODUCT INSTALLATION
4.1 - Electrical connections
WARNING - Before making the connections, ensure that the control unit is not powered up.
MOTOR CONNECTOR
Power supply connection terminal board
L1 Motor live
COM Motor common
L2 Motor live
DIP SWITCH
Set on "ON" to disable inputs EDGE, PH2, PH1, STOP.
Eliminates the need to bridge the terminal board inputs.
WARNING - with the dip switch ON, the safety
devices are disabled
1
GND
_
AC/DC
18
L
N
2 1 2
12/24
GND 12/24
_
AC/DC
TX
RX
PH2
POWER SUPPLY CONNECTOR
L Power supply live 230 Vac (120 Vac) 50-60 Hz
N Power supply neutral 230 Vac (120 Vac) 50-60 Hz
COM Vac Common of the "CR" and "FLASH" outputs
CR Courtesy light, 230 Vac (120 Vac) 100 W
FLASH Flashing light, 230 Vac (120 Vac) 40 W
3 4
COM OUT
NC
OUTPUT
24 Vdc
2
1 1 2
GND 12/24
GND
_
_
AC/DC
AC/DC
TX
PH1
3 4
12/24 COM OUT
NC
RX
