Chapter 2 Installation
TherearplatecontainstheOn/Offswitch,theACpowercord
Rear
receptacle,andvariousinterfaceconnectorsandslots.
View
10
Provision for optional Interface Boards
Bar Code Wand Connector
On/Off Switch
Not used
AC Power Cord Receptacle
RS-232 Serial Interface Connector ("uart1:")
Upper External Media Intake
Centronics Parallel Interface
Memory Card Slot
Machine Label
Lower External Media Intake
Intermec EasyCoder 501 XP – User 's Guide
