Itmustnotcutthroughanyadhesive,whichwouldsticktothe
cuttingpartsandrapidlyrenderthecutterinoperable–possibly
alsocausingdamagetotheelectricmotor.Maximumthickness
fornormalpaper-basedmaterialsis175µm(≈175grammes/m
).
2
Thepapercutterincreasestheprinter'stotalweightbyapprox.
1.0kgs(2.2pounds)anditslengthby28mm(1.1inches.)
Thepapercuttercanbetiltedforwardinordertofacilitate
cleaningandmediaload.Formedialoadinstructions,seesection
"Cut-Off"inChapter4,"MediaLoad."
ThecutterisactivatedbyCUTorCUTONinstructions,see
the IntermecFingerprintv7.xx manuals . Therotatingedgewillcut
throughthemediaapprox.37mm(1.5inches)infrontofthe
Intermec EasyCoder 501 XP – User's Guide
